Parameters

4.13 Main Menu - Data Readouts - Group 16

4.13.1 16-0* General Status
16-00 Control Word
Range:
0 [0 - 65535 ] View the control word sent from the frequency
*
4 4
Bit Bit=0
00 Preset reference option lsb
01 Preset reference option 2
preset references
02 DC brake
03 Coasting
04 Quick stop
05 Freeze output
06 Ramp stop
07 No function
08 No function
09 Ramp 1
10 Data not valid
11 Relay_A not active
12 Relay_B not active
13 Choice of set-up lsb
14 No function
15 No function
Table 4.8 Control Word
16-01 Reference [Unit]
Range:
0 ReferenceFeed-
backUnit
*
16-02 Reference [%]
Range:
0 % [-200 - 200 %] View the total reference. The total
*
16-03 Status Word
Range:
0 [0 - 65535 ] View the status word sent from the frequency
*
96
VLT
Function:
converter via the serial communication port in
hex code.
Bit=1
–
–
nd bit of
Ramp
Enable
Ramp
Ramp
Start
Reset
Jog
Ramp 2
Valid
Relay_A activated
Relay_B activated
–
No function
Reversing
Function:
[-4999 - 4999 View the present reference
ReferenceFeed- value applied on impulse
backUnit] or analog basis in the unit
resulting from the configu-
ration selected in
parameter 1-00 Configu-
ration Mode (Hz).
Function:
reference is the sum of digital, analog,
preset, bus, and freeze references.
Function:
converter via the serial communication port in
hex code.
Danfoss A/S © 11/2015 All rights reserved.
®
DriveMotor FCP 106/FCM 106
Bit Bit=0
00 Control not ready
01 VLT not ready
02 Coasting
03 No fault
04 No warning
05 Reserved
06 No trip lock
07 No warning
08 Speed≠ref.
09 Local control
10 Out of range
11 Not running
12 No function
13 Voltage OK
14 Current OK
15 Temperature OK
Table 4.9 Status Word
16-05 Main Actual Value [%]
Range:
0 % [-200 - 200 %] View the 2-byte word sent with the status
*
16-09 Custom Readout
Range:
0 CustomRea-
doutUnit
*
4.13.2 16-1* Motor Status
16-10 Power [kW]
Range:
0 kW [0 - 1000
*
kW]
16-11 Power [hp]
Range:
0 hp [0 - 1000
*
hp]
Bit=1
Ready
Ready
Enable
Trip
Warning
–
Trip lock
Warning
Speed=ref.
Bus control
Frequency OK
Running
No function
Above limit
Above limit
Above limit
Function:
word to the bus master reporting the
main actual value.
Function:
[0 - 9999 View the user-defined readouts
CustomRea- as defined in
doutUnit] parameter 0-30 Custom Readout
Unit, parameter 0-31 Custom
Readout Min Value, and
parameter 0-32 Custom Readout
Max Value.
Function:
Shows DC link power in kW. The value
shown is calculated based on the actual
motor voltage and motor current.
Function:
View the the actual motor power in hp. The
value shown is calculated on the basis of
the actual motor voltage and motor
current.
