Programming

2.4 Programming Parameters

Procedure:
1. Press [Menu] until the arrow in the display
indicates the wanted menu: Quick Menu or Main
Menu.
2. To browse through the parameter groups, press
▲ ▼
[ ] [ ].
3. To select a parameter group, press [OK].
4. To browse through the parameters in the specific
▲ ▼
group, press [ ] [ ].
5. To select the parameter, press [OK].
6.
To change the parameter value, press [
7. To save the new setting, press [OK]. To abort,
press [Back].
8. To return to the previous menu, press [Back].
2.5 Back-up and Copying Parameter
Settings
NOTICE
Stop the motor before backing-up or copying parameter
settings.
Data storage in LCP
Once the set-up of a frequency converter is complete,
store the data in the LCP. Alternatively, use a PC with the
MCT 10 Set-up Software to perform the same back-up.
1. Go to parameter 0-50 LCP Copy.
2. Press [OK].
3. Select [1] All to LCP.
4. Press [OK].
Data transfer from LCP to frequency converter
Connect the LCP to another frequency converter and copy
the parameter settings to this frequency converter as well.
1. Go to parameter 0-50 LCP Copy.
2. Press [OK].
3. Select [2] All from LCP.
4. Press [OK].
MG03N202
Programming Guide

2.6 Restoring Default Settings

Select initialization mode according to the requirement for
retaining parameter settings.
Recommended initialization (via
parameter 14-22 Operation Mode).
Use this method to initialize the frequency converter
without resetting communication settings.
1.
2.
3.
4.
▲ ▼ ▶
] [ ] [ ].
5.
The frequency converter is now reset, except for the
following parameters:
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Danfoss A/S © 11/2015 All rights reserved.
Select parameter 14-22 Operation Mode.
Press [OK].
Select [2] initialization and Press [OK].
Cut off the mains supply and wait until the
display turns off.
Reconnect the mains supply.
Parameter 0-03 Regional Settings.
Parameter 8-30 Protocol.
Parameter 8-31 Address.
Parameter 8-32 Baud Rate.
Parameter 8-33 Parity / Stop Bits.
Parameter 8-35 Minimum Response Delay.
Parameter 8-36 Maximum Response Delay.
Parameter 8-70 BACnet Device Instance.
Parameter 8-72 MS/TP Max Masters.
Parameter 8-73 MS/TP Max Info Frames.
Parameter 8-74 "I am" Service.
Parameter 8-75 Intialisation Password.
Parameter 15-00 Operating hours.
Parameter 15-03 Power Up's.
Parameter 15-04 Over Temp's.
Parameter 15-05 Over Volt's.
Parameter 15-30 Alarm Log: Error Code.
Parameter group 15-4* Drive identification
parameters.
Parameter 1-06 Clockwise Direction.
