Parameters
4.8 Main Menu - Communications and
Options - Group 8
4.8.1 8-0* General Settings
8-01 Control Site
Option: Function:
This parameter overrules settings in
parameter 8-50 Coasting Select to
parameter 8-56 Preset Reference Select.
[0] Digital and Control by using both digital input and
*
ctrl.word control word.
[1] Digital only Control by using digital inputs only.
[2] Controlword Control by using control word only.
only
8-02 Control Source
Option: Function:
NOTICE
This parameter cannot be adjusted while
the motor is running.
Select the source of the control word.
[0] None
[1] FC Port
[3] Option A PROFIBUS and PROFINET.
8-03 Control Timeout Time
Range: Function:
1 s [0.1 - Enter the maximum time expected to pass
*
6000 s] between the reception of 2 consecutive
telegrams. If this time is exceeded, it indicates
that the serial communication has stopped. The
function selected in parameter 8-04 Control
Timeout Function Control Timeout Function is
carried out.
8-04 Control Timeout Function
Option: Function:
Select the timeout function. The timeout
function is activated when the control
word fails to be updated within the time
period specified in parameter 8-03 Control
Timeout Time. Option [20] N2 Override
Release only appears after setting the
Metasys N2 protocol.
[0] Off
*
[1] Freeze output
[2] Stop
[3] Jogging
[4] Max. speed
[5] Stop and trip
MG03N202
Programming Guide
8-04 Control Timeout Function
Option:
[20] N2 Override
Release
8-07 Diagnosis Trigger
Option:
[0] Disable
*
[1] Trigger on
alarms
[2] Trigger
alarm/warn.
4.8.2 8-1* Ctrl. Word Settings
8-10 Control Word Profile
Option:
[0] FC profile
*
[1] PROFIdrive
profile
8-14 Configurable Control Word CTW
Option:
[0] None
[1] Profile
*
default
[2] CTW Valid,
active low
8-19 Product Code
Range:
Size
related
*
Danfoss A/S © 11/2015 All rights reserved.
Function:
Function:
Select [0] Disable to send no extended
diagnosis data (EDD). Select [1] Trigger on
alarms to send EDD upon alarms or [2]
Trigger alarm/warn. to send EDD upon alarms
or warnings. Not all fieldbusses support the
diagnosis functions.
Function:
Select the interpretation of the control
and status words corresponding to the
installed fieldbus. Only the selections valid
for the fieldbus installed in slot A are
visible in the LPC display.
Function:
The frequency converter ignores the
information in this bit.
The functionality of the bit is depending on
the selection parameter 8-10 Control Word
Profile.
If set to 1, the frequency converter ignores
the remaining bits of the control word.
Function:
[0 - Select 0 to readout the actual
2147483647] fieldbus product code according
to the mounted fieldbus option.
Select 1 to readout the actual
vendor ID.
