Operation/Display; Load And Motor - Danfoss VLT DriveMotor FCP 106 Programming Manual

Parameter Lists

6.1.2 0-** Operation/Display

Par. Parameter description
No. #
0-0* Basic Settings
0-01 Language
0-03 Regional Settings
0-04 Operating State at Power-up
0-06 GridType
0-07 Auto DC Braking
0-1* Set-up Operations
0-10 Active Set-up
0-11 Programming Set-up
0-12 Link Setups
6 6
0-2* LCP Display
0-20 Display Line 1.1 Small
0-21 Display Line 1.2 Small
0-22 Display Line 1.3 Small
0-23 Display Line 2 Large
0-24 Display Line 3 Large
0-3* LCP Custom Readout
0-30 Custom Readout Unit
0-31 Custom Readout Min Value
0-32 Custom Readout Max Value
0-37 Display Text 1
0-38 Display Text 2
0-39 Display Text 3
0-4* LCP Keypad
0-40 [Hand on] Key on LCP
0-42 [Auto on] Key on LCP
0-44 [Off/Reset] Key on LCP
0-5* Copy/Save
0-50 LCP Copy
0-51 Set-up Copy
0-6* Password
0-60 Main Menu Password

6.1.3 1-** Load and Motor

Par. Parameter description
No. #
1-0* General Settings
1-00 Configuration Mode
1-01 Motor Control Principle
1-03 Torque Characteristics
1-06 Clockwise Direction
1-08 Motor Control Bandwidth
1-1* Motor Selection
1-10 Motor Construction
1-11 Motor Selection
1-12 Motor ID
1-14 Damping Gain
1-15 Low Speed Filter Time Const.
1-16 High Speed Filter Time Const.
128
®
VLT DriveMotor FCP 106/FCM 106
Default value
[0] English
[0] International
[0] Resume
ExpressionLimit
[1] On
[1] Set-up 1
[9] Active Set-up
[20] Linked
1602
1614
1610
1613
1502
[1] %
0 CustomReadoutUnit
100 CustomReadoutUnit
0 N/A
0 N/A
0 N/A
[1] Enabled
[1] Enabled
[1] Enabled
[0] No copy
[0] No copy
0 N/A
Default value
[0] Open Loop
[1] VVC+
[1] Variable Torque
[0] Normal
ExpressionLimit
[0] Asynchron
[0] Default Motor Selection
[Default Motor]
120%
ExpressionLimit
ExpressionLimit
Danfoss A/S © 11/2015 All rights reserved.
4-set-up Change during
operation
1 set-up TRUE
1 set-up FALSE
All set-ups TRUE
1 set-up FALSE
1 set-up FALSE
1 set-up TRUE
1 set-up TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up FALSE
1 set-up FALSE
1 set-up TRUE
4-set-up Change during
operation
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
1 set-up FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Conversion Type
index
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint16
- Uint16
- Uint16
- Uint16
- Uint16
- Uint8
-2 Int32
-2 Int32
0 VisStr[20]
0 VisStr[25]
0 VisStr[25]
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Uint16
Conversion Type
index
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- uint8
0 VisStr[16]
0 Int16
-2 Uint16
-2 Uint16
MG03N202
