Parameters

4.9 Main Menu - PROFIdrive - Group 9

9-00 Setpoint
Range: Function:
0 [0 - This parameter receives cyclic reference from a
*
65535 ] master class 2. If the control priority is set to
master class 2, the reference for the frequency
converter is taken from this parameter, whereas
the cyclic reference is ignored.
9-07 Actual Value
Range: Function:
0 [0 - 65535 ] This parameter delivers the MAV for a master
*
class 2. The parameter is valid if the control
priority is set to master class 2.
9-15 PCD Write Configuration
Select the parameters to be assigned to PCD 3–10 of the
telegrams. The number of available PCDs depends on the
telegram type. Values in PCD 3–10 are written to the selected
parameters as data. For standard PROFIBUS telegrams, see
parameter 9-22 Telegram Selection.
Option:
[0]
[302] Minimum Reference
[303] Maximum Reference
[312] Catch up/slow Down Value
[341] Ramp 1 Ramp Up Time
[342] Ramp 1 Ramp Down Time
[351] Ramp 2 Ramp Up Time
[352] Ramp 2 Ramp Down Time
[380] Jog Ramp Time
[381] Quick Stop Ramp Time
[412] Motor Speed Low Limit [Hz]
[414] Motor Speed High Limit [Hz]
[553] Term. 29 High Ref./Feedb.
Value
[590] Digital & Relay Bus Control
[615] Terminal 53 High Ref./Feedb.
Value
[625] Terminal 54 High Ref./Feedb.
Value
[696] Terminal 42 Output Bus
Control
[890] Bus Jog 1 Speed
[891] Bus Jog 2 Speed
[894] Bus Feedback 1
[1680] Fieldbus CTW 1
[1682] Fieldbus REF 1
[2021] Setpoint 1
MG03N202
Programming Guide
9-16 PCD Read Configuration
Select the parameters to be assigned to PCD 3–10 of the
telegrams. The number of available PCDs depends on the
telegram type. Values in PCD 3–10 contain the actual data values
of the selected parameters.
Option:
[0]
[894]
[1500]
[1501]
[1502]
[1600]
[1601]
[1602]
[1603]
[1605]
[1609]
[1610]
[1611]
[1612]
[1613]
[1614]
Function:
[1615]
[1616]
[1618]
[1622]
[1626]
[1627]
[1630]
[1634]
[1635]
[1638]
[1639]
[1650]
[1652]
[1660]
[1661]
[1662]
[1663]
[1664]
[1665]
[1666]
[1667]
[1671]
[1672]
[1673]
[1679]
[1684]
[1685]
[1690]
[1691]
[1692]
[1693]
[1694]
Danfoss A/S © 11/2015 All rights reserved.
Bus Feedback 1
Operating hours
Running Hours
kWh Counter
Control Word
Reference [Unit]
Reference [%]
Status Word
Main Actual Value [%]
Custom Readout
Power [kW]
Power [hp]
Motor Voltage
Frequency
Motor current
Frequency [%]
Torque [Nm]
Motor Thermal
Torque [%]
Power Filtered [kW]
Power Filtered [hp]
DC Link Voltage
Heatsink Temp.
Inverter Thermal
SL Controller State
Control Card Temp.
External Reference
Feedback[Unit]
Digital Input
Terminal 53 Setting
Analog Input AI53
Terminal 54 Setting
Analog Input AI54
Analog Output AO42 [mA]
Digital Output
Pulse Input #29 [Hz]
Relay Output [bin]
Counter A
Counter B
Analog Output AO45
Comm. Option STW
FC Port CTW 1
Alarm Word
Alarm Word 2
Warning Word
Warning Word 2
Ext. Status Word
Function:
