Parameter Lists

6.1.4 2-** Brakes

Par. Parameter description
No. #
2-0* DC-Brake
2-00 DC Hold/Motor Preheat Current
2-01 DC Brake Current
2-02 DC Braking Time
2-04 DC Brake Cut In Speed
2-06 Parking Current
2-07 Parking Time
2-1* Brake Energy Funct.
2-10 Brake Function
6 6
2-16 AC Brake, Max current
2-17 Over-voltage Control
2-2* Mechanical Brake
2-20 Release Brake Current
2-22 Activate Brake Speed [Hz]

6.1.5 3-** Reference/Ramps

Par. Parameter description
No. #
3-0* Reference Limits
3-02 Minimum Reference
3-03 Maximum Reference
3-1* References
3-10 Preset Reference
3-11 Jog Speed [Hz]
3-12 Catch up/slow Down Value
3-14 Preset Relative Reference
3-15 Reference 1 Source
3-16 Reference 2 Source
3-17 Reference 3 Source
3-4* Ramp 1
3-41 Ramp 1 Ramp Up Time
3-42 Ramp 1 Ramp Down Time
3-5* Ramp 2
3-51 Ramp 2 Ramp Up Time
3-52 Ramp 2 Ramp Down Time
3-8* Other Ramps
3-80 Jog Ramp Time
3-81 Quick Stop Ramp Time
3-85 Check Valve Ramp Time
3-87 Check Valve Ramp End Speed [HZ]
130
®
VLT DriveMotor FCP 106/FCM 106
Default value
50%
50%
10 s
0 Hz
100%
3 s
[0] Off
100%
[2] Enabled
0 A
0 Hz
Default value
0 ReferenceFeedbackUnit
ExpressionLimit
0%
5 Hz
0%
0%
[1] Analog Input 53
[2] Analog Input 54
[11] Local bus reference
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
0 s
ExpressionLimit
Danfoss A/S © 11/2015 All rights reserved.
4-set-up Change
during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
4-set-up Change
during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
Conversion Type
index
0 Uint16
0 Uint16
-1 Uint16
-1 Uint16
0 Uint16
-1 Uint16
- Uint8
-1 Uint16
- Uint8
-2 Uint32
-1 Uint16
Conversion Type
index
-3 Int32
-3 Int32
-2 Int16
-1 Uint16
-2 Int16
-2 Int16
- Uint8
- Uint8
- Uint8
-2 Uint32
-2 Uint32
-2 Uint32
-2 Uint32
-2 Uint32
-2 Uint32
-2 Uint16
-1 Uint16
MG03N202
