Selection Guide | VLT® AutomationDrive FC 300 Series
Versatile, reliable and
consistently awesome
Intelligence
to empower
your industrial
applications
drives.danfoss.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VLT AutomationDrive FC 300 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Danfoss VLT AutomationDrive FC 300 Series

Summary of Contents for Danfoss VLT AutomationDrive FC 300 Series

  • Page 1 Selection Guide | VLT® AutomationDrive FC 300 Series Versatile, reliable and consistently awesome Intelligence to empower your industrial applications drives.danfoss.com...

  • Page 2: Table Of Contents

    Electrical data – A, B, and C enclosures ..........30 Tailored safety ...................... 17 Dimensions enclosure sizes A, B and C ..........34 Free to connect ....................18 Ordering typecode for A, B and C enclosures ......... 35 Danfoss Drives · DKDD.PB.302.A8.02...
  • Page 3 Read on to find out about the new generation E-frames and the lower temperature rating. As with all Danfoss drives, the VLT® AutomationDrive is motor independent giving you the power to choose the motor that best suits your application.

  • Page 4: Seamlessly Into The Future

    At Danfoss Drives, we live and breathe Industry 4.0, with the VLT® HCS for harmonic calculation and AutomationDrive representing the Danfoss ecoSmart™ for motor-drive latest and best technologies in the system efficiency calculations Danfoss Drives · DKDD.PB.302.A8.02 | Content |...

  • Page 5: Consistently Awesome

    DrivePro® services proactively improve productivity, performance and uptime. Its cutting-edge thermal design and unique back-channel cooling for drives above 90 kW make VLT® AutomationDrive one of the most compact and cost-efficient drives in the market. | Content | Danfoss Drives · DKDD.PB.302.A8.02...

  • Page 6: Designed For Easy Integration In Any Application

    – close to the motor, located centrally critical to keeping costs low. The 1. Fits in any environment in an electrical panel or outdoors. Danfoss HCS tool allows you to 2. Modular and adaptable Its wide variety of enclosure class, calculate how much harmonic content 3.

  • Page 7: Designed With Fast And Easy Start-Up In Mind

    Designed with fast Simple start-up and easy start-up in mind Your choice of AC drive should reduce the time it takes to get your application up and running without sacrificing any features or functionality. The VLT® AutomationDrive FC 300 Series is designed to simplify every step in the start- up process –...

  • Page 8: Extensive Functionality For High-Performance Operation

    (EMI) to meet these coming requirements. – both conducted and and emitted. Using Danfoss ecoSmart™, you can This interference can negatively impact quickly determine the IE class of your sensitive equipment. Built-in EMC/...

  • Page 9: Leveraging Digitalization To Reduce Maintenance Costs

    Utilizing the integrated and personnel, Danfoss service teams, and modernized interface of the web server 3rd-party service providers for fast and in the Ethernet-based communication remote monitoring purposes.

  • Page 10: Flexible, Modular And Adaptable Built To Last

    This means that system motor types and foster ongoing parameter settings for your unique designers, OEMs and end users are free development as new technologies application. to connect the drive to their selected emerge. Danfoss Drives · DKDD.PB.302.A8.02 | Content |...
  • Page 11 IEC: IP00, IP20, IP21, IP54, IP55, IP66 Programmable digital output changeable UL: Chassis, Type 1, Type 12, Type 4X Programmable relay output * For frequency up to 1000 Hz please contact your local Danfoss partner. | Content | Danfoss Drives · DKDD.PB.302.A8.02...

  • Page 12: Stand-Alone Drives, Enclosed Drives, Modules

    VLT® drives virtually features that VLT® drives offer as performance maintenance free standard, there are numerous other control, monitoring and power options available in pre-engineered factory configurations Danfoss Drives · DKDD.PB.302.A8.02 | Content |...

  • Page 13: Application Flexibility To Boost Your Business

    Propulsion, thrusters „ Winches „ Vertical and horizontal movement „ „ „ „ „ „ „ „ „ „ Power conversion generation, smart grids „ „ „ Positioning, synchronization „ „ „ „ „ | Content | Danfoss Drives · DKDD.PB.302.A8.02...

  • Page 14: Integrated Motion Controller - For Positioning And Synchronization Applications

    Configuration via parameters, with Rotary tables no advanced programming required. Cutting machines Reduced complexity will minimize Packaging machines the risk of errors Danfoss Drives · DKDD.PB.302.A8.02 | Content |...
  • Page 15 | Content | Danfoss Drives · DKDD.PB.302.A8.02...

  • Page 16: Increase Precision, Accuracy And Speed

    VLT® Motion return on your investment. Control Option MCO 305, both adds Danfoss Drives · DKDD.PB.302.A8.02 | Content |...

  • Page 17: Tailored Safety

    The software also offers easy diagnosis and a dynamic commissioning report AC drive which can be used for supplying without STO certification documentation necessary for safety acceptance tests. After AC drive with STO (FC 302) Actuator | Content | Danfoss Drives · DKDD.PB.302.A8.02...

  • Page 18: Free To Connect

    The drive and fieldbus can also be see fit. while providing improved systems configured using the software tools performance. that support each drive family. Danfoss Drives offers fieldbus drivers and PLC Increase productivity examples for free from the Danfoss User friendly and fast setup...

  • Page 19: Customized Commissioning Experience

    The motor types supported by the motor plug-in are: „ „ Asynchronous „ „ PM, non-salient SPM „ „ PM, salient IPM „ „ Synchronous Reluctance (SynRM) | Content | Danfoss Drives · DKDD.PB.302.A8.02...

  • Page 20: Modular Simplicity - A, B And C Enclosures

    RS485 connection or through fieldbus options with the VLT® 6. Fieldbus option Motion Control Tool MCT 10 PC tool. All major industrial fieldbuses are supported. See complete list of available fieldbus options on page 41. Danfoss Drives · DKDD.PB.302.A8.02 | Content |...

  • Page 21: Vlt® Wireless Communication Panel Lcp 103

    Please see chapter personnel can receive real-time error “Tailored safety” on page 17. messages via the app to ensure a quick response to potential issues and reduce downtime. | Content | Danfoss Drives · DKDD.PB.302.A8.02...

  • Page 22: High-Power Modularity - D, E And F Enclosures

    G3. Additionally, drives in D and E disconnect switch, or RFI filter. loaded cage clamps add to reliability enclosures can be further ruggedized and facilitate easy commissioning and to withstand the higher vibration needs service. of certain applications. Danfoss Drives · DKDD.PB.302.A8.02 | Content |...
  • Page 23 Energy is saved and electronics last longer because they are not exposed to high temperatures within the enclosure. Safety Extended range of integrated functional safety. Please see chapter “Tailored safety” on page 17. | Content | Danfoss Drives · DKDD.PB.302.A8.02...

  • Page 24: Engineered For Cost Savings Via Intelligent Heat Management, Compactness And Protection

    All Danfoss VLT® drives follow the same design principle for fast, flexible and fault-free installation, and efficient cooling. The AC drives are available in a broad contaminants. At the same time, it In daily use, the benefits are equally...
  • Page 25 By directing air through a rear cooling channel cooling air and the internal channel, up to 90% of the drive’ s heat electronics ensures efficient cooling. loss is removed directly outside the installation room. | Content | Danfoss Drives · DKDD.PB.302.A8.02...

  • Page 26: Optimize Performance And Grid Protection

    These built-in components save cabinet space, as they are integrated in the drive from the factory. Efficient EMC mitigation also enables the use of cables with smaller cross-sections, which reduces installation costs. Danfoss Drives · DKDD.PB.302.A8.02 | Content |...

  • Page 27: Drivepro® Life Cycle Service Products

    You’re covered with DrivePro® Life Cycle service products Get the most out of your systems, with the help of DrivePro® services for Danfoss VLT® and VACON® drives. You get services that go beyond DrivePro® app simple troubleshooting, maintenance, repairs and replacements.

  • Page 28: Connection Example

    53 (V or mA), and for 54 (V or mA) status or warning or can be used as a terminals. pulse reference signal. The terminal 42 analog output can show process values such as 0 - Imax. Danfoss Drives · DKDD.PB.302.A8.02 | Content |...

  • Page 29: Technical Data

    500 Ω analog output (clamp 30) – Predictive maintenance Accuracy on analog output Max. error: 0.5 % of full scale – Preventive maintenance – D-option VLT® Real-time Clock Option MCB 117 Agency approvals | Content | Danfoss Drives · DKDD.PB.302.A8.02...

  • Page 30: Electrical Data - A, B, And C Enclosures

    P5K5 30.8 33.9 30.8 P7K5 46.2 50.8 46.2 P11K 59.4 65.3 59.4 P15K 74.8 82.3 18.5 74.8 P18K 96.8 P22K 1140 P30K 1353 P37K 1636 *A1 enclosure is only available as FC 301 Danfoss Drives · DKDD.PB.302.A8.02 | Content |...
  • Page 31 31.9 P15K 37.5 41.3 37.4 18.5 37.4 P18K 48.4 P22K 67.1 57.2 60.5 P30K 80.3 71.5 72.6 P37K 90.2 P45K 1083 P55K 1384 P75K 1474 *A1 enclosure is only available as FC 301 | Content | Danfoss Drives · DKDD.PB.302.A8.02...
  • Page 32 Type 4X (60 s) 575 V 575 V PK75 0.75 P1K1 P1K5 P2K2 P3K0 P4K0 P5K5 14.4 13.8 P7K5 17.6 16.6 P11K P15K 18.5 P18K P22K P30K P37K P45K 1100 P55K 1500 P75K 1800 Danfoss Drives · DKDD.PB.302.A8.02 | Content |...
  • Page 33 53.9 P37K 59.4 57.2 64.9 P45K 71.5 68.2 78.1 1100 P55K 95.7 91.3 95.7 1500 – P75K 115.5 108.9 1800 – *Note: T7 drives are not UL certified. Select T6 for UL certification. | Content | Danfoss Drives · DKDD.PB.302.A8.02...

  • Page 34: Dimensions Enclosure Sizes A, B And C

    50.7 59.6 26.5 99.3 143.3 77.2 110.2 A3 IP20/Chassis A3 IP20 with option C A3 with IP21/Type 12 NEMA 1 Kit with decoupling plate A4 IP55 with mains disconnect B4 IP20 C3 IP20 Danfoss Drives · DKDD.PB.302.A8.02 | Content |...

  • Page 35: Ordering Typecode For A, B And C Enclosures

    IP66 / UL Type 4X enclosures VLT® EtherCAT MCA 124 IP66 / Type 4X VLT® 5000 DeviceNet Converter MCA 194 IP66 / Type 4X + backplate (A4 enclosure, no C-options) IP66 / Type 4X (A4 enclosure, no C-options) | Content | Danfoss Drives · DKDD.PB.302.A8.02...

  • Page 36: Electrical Data - D, E And F Enclosures

    1260 1386 1160 1276 1000 1227 14674 – F1/F3 F1/F3 P710 1460 1606 1380 1518 1200 1422 17293 – F2/F4 F2/F4 P800 1720 1892 1530 1683 1000 1350 1675 19278 – F2/F4 F2/F4 Danfoss Drives · DKDD.PB.302.A8.02 | Content |...
  • Page 37 – F2/ F4 F2/ F4 P1M0 1317 1449 1260 1386 1200 1350 1282 15865 – F2/ F4 F2/ F4 P1M2 1479 1627 1415 1557 1400 1550 1440 18173 – F2/ F4 F2/ F4 | Content | Danfoss Drives · DKDD.PB.302.A8.02...

  • Page 38: Dimensions Enclosure Sizes D, E And F

    86.8 86.8 Height [in] Width 23.7 27.5 199.9 23.9 55.2 70.9 78.8 94.5 20.2 20.2 19.0 19.0 23.9 23.9 23.9 23.9 Depth 650.0 700.0 600.0 650.0 2242.1 2777.9 2905.7 3441.5 [lb] Weight D3h/D4h Danfoss Drives · DKDD.PB.302.A8.02 | Content |...

  • Page 39: Electrical Data And Dimensions - Vlt® 12-Pulse

    12338 P560 1120 1232 1050 1155 1090 13201 P630 1260 1386 1160 1276 1000 1227 15436 P710 1460 1606 1380 1518 1200 1422 18084 P800 1720 1892 1530 1683 1000 1350 1675 20358 | Content | Danfoss Drives · DKDD.PB.302.A8.02...
  • Page 40 1259.0 [kg] Weight 86.8 86.8 86.8 86.8 86.8 86.8 Height 31.5 55.2 63.0 94.5 78.8 110.2 [in] Width 23.9 23.9 23.9 23.9 23.9 23.9 Depth Weight 985.5 1474.9 1968.8 2460.4 2286.4 2775.7 [lb] Danfoss Drives · DKDD.PB.302.A8.02 | Content |...
  • Page 41 VLT® 12-pulse VLT® 12-pulse | Content | Danfoss Drives · DKDD.PB.302.A8.02...

  • Page 42: Ordering Typecode For D, E And F Enclosures

    + USB through door IRM for IT mains with Class A2 RFI (D1h, D5h, D6h enclosures) (Enclosure sizes F1, F2, F3, F4) IP21 / Type 1 – Stainless steel back channel + space heater Danfoss Drives · DKDD.PB.302.A8.02 | Content |...
  • Page 43 Two 2.5-4 A manual motor starters VLT® Safety Option MCB 150 TTL Two 4-6.3 A manual motor starters VLT® Safety Option MCB 151 HTL Two 6.3-10 A manual motor starters Two 10-16 A manual motor starters | Content | Danfoss Drives · DKDD.PB.302.A8.02...

  • Page 44: Electrical Data - Vlt® Low Harmonic Drive And Vlt® Advanced Active Filters

    9000 A400 11100 * Built-in options for fuses and disconnect recommended Typecode VLT® Advanced Active Filter The different VLT® Active Filters can easily be configured according to customer request at drives.danfoss.com 8-10: 16-17: 13-15: 190: 190 A correction current E54: IP 54/NEMA 12...
  • Page 45 , 25 in selective mode Progressive control in the range of Switching frequency 3 – 18 kHz Average switching frequency 3 – 4.5 kHz VLT® Advanced Active Filter AAF 006 VLT® Low Harmonic Drive | Content | Danfoss Drives · DKDD.PB.302.A8.02...

  • Page 46: A Options: Fieldbuses

    VLT® AutomationDrive, or an existing system can be expanded without costly change of the Order code 130B1119 standard, dual-port PLC program. 130B1219 coated, dual-port The option supports DPV1. VLT® 5000 PROFIBUS Converter MCA 114 Order code 130B1246 coated Danfoss Drives · DKDD.PB.302.A8.02 | Content |...

  • Page 47: B Options: Functional Extensions

    130B1127 standard „ Spring-loaded connection „ EnDat 2.1 and 2.2 130B1227 coated (Class 3C3/IEC 60721-3-3) Ordering number Ordering number 130B1125 standard 130B1115 standard 130B1212 coated (Class 3C3/IEC 60721-3-3) 130B1203 coated (Class 3C3/IEC 60721-3-3) | Content | Danfoss Drives · DKDD.PB.302.A8.02...
  • Page 48 Back-up supply for the standard clock func- 130B3280 MCB 150, 130B3290 MCB 151 tion in the AC drive The back-up battery typically lasts for 10 years, depending on environment. Ordering number 130B1143 standard 130B1243 coated (Class 3C3/IEC 60721-3-3) Danfoss Drives · DKDD.PB.302.A8.02 | Content |...

  • Page 49: C Options: Motion Control And Relay Card

    (max. 37 V for 10 sec.) „ „ Max. input current ..........2.2 A „ „ Max. cable length ..........75 m „ „ Input capacitance load ......< 10 uF „ „ Power-up delay ..........< 0.6 s | Content | Danfoss Drives · DKDD.PB.302.A8.02...

  • Page 50: Accessories

    130B5645: A2-A3 130B5764: B3 130B5765: B4 130B6226: C3 130B5647: C4 PC software VLT® Motion Control Tool MCT 10 VLT® Motion Control Tool MCT 31 Danfoss HCS Harmonic Calculation Software VLT® Energy Box Danfoss ecoSmart™ Danfoss Drives · DKDD.PB.302.A8.02 | Content |...

  • Page 51: Power Options

    (Forced cooling is required. There is no fan in the IP00 unit. Separate cooling measures Ordering number must be implemented in the cabinet as part See relevant Design Guide of the installation) Ordering number See relevant Design Guide | Content | Danfoss Drives · DKDD.PB.302.A8.02...

  • Page 52: Accessory Compatibility With Enclosure Size

    – – – – NEMA 3R ready drive – – – – – – – – – – – – – Options supplied with fuses Not available in 690 V Optional „ Standard Danfoss Drives · DKDD.PB.302.A8.02 | Content |...
  • Page 53 (IT) system. „ Integrated into the drive’s Safe Torque Off circuit „ LCD display of insulation resistance „ Fault memory „ INFO, TEST and RESET key | Content | Danfoss Drives · DKDD.PB.302.A8.02...

  • Page 54: Loose Kits For Enclosure Sizes D, E And F

    F1/F3, 600 mm ............176F1839 F2/F4 400 mm ............176F1840 Ordering number F2/F4, 600 mm ............176F1841 Enclosure sizes D ..........130B1155 F8, F9, F10, F11, F12, F13 ....Contact factory Enclosure sizes E ..........130B1156 Enclosure sizes F ..........176F1784 Danfoss Drives · DKDD.PB.302.A8.02 | Content |...
  • Page 55 800 mm bottom plate ........176F6607 D3h back-channel cooling kit (in back out back)..........176F3633 E4h (in bottom/out top) D4h Back-channel cooling kit 800 mm bottom plate ........176F6608 E3h (in back/out back) ........176F6610 (in back out back)..........176F3634 | Content | Danfoss Drives · DKDD.PB.302.A8.02...
