Daisy Chain Remote Secondary ID
Note: Not in ESP.
Usage: This command provides a handy way to assign custom daisy chain IDs to
specific readers that were assigned during the daisy chain autoconfigure
process.
Definition: Assigns a new daisy chain ID to a daisy chain secondary reader. The com-
mand is sent to the master reader to configure the other secondary read-
ers.
Daisy Chain Reader Number
Definition: Specifies the target reader (by sequential number) which will be receiving
the new Daisy Chain ID. The master reader is always 0 (zero). All second-
ary readers are numbered 1...n in the order that they are connected.
Note: These numbers are for assigning IDs only and are not
changeable.
Serial Cmd: <K151,daisy chain reader
Options: 1....n (0 for the master reader)
Daisy Chain Reader ID
Definition: A two-character user-defined ASCII message identifying a reader in the
daisy chain.
Serial Cmd: <K151,daisy chain reader
Default: Sequential numbering of reader units resulting from the Daisy Chain
Auto-configure
ID Reader 1 = 2/; ID Reader 2 = 3/; etc.
Options: Any two characters except
Note: After a secondary reader accepts a new ID, it automatically invokes a reset-with-
save command.
MS-860 Industrial Raster Reader User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
#,daisy chain reader ID>
#,daisy chain reader
<K150DAISY> command; for example: ID Master = 1/;
NULL < , or >.
Communications
ID>
6-17
