Serial Trigger

Serial Trigger

Usage: Defines the trigger character that initiates the read cycle.
Definition: An on-line host command composed of a single ASCII host serial trigger
character that initiates or ends the read cycle.
Trigger characters are of two types: delimited and non-delimited. A
delimited character is enclosed within angle bracket delimiters
A non-delimited trigger character is one that either starts or ends the
read cycle and is NOT enclosed by delimiters such as
Serial Trigger Character
Usage: Useful in applications where a single serial character enclosed in angle
brackets initiates the read cycle.
Definition: A trigger character is one that starts the read cycle, is enclosed by delim-
iters < >
Data or Serial Data & Edge.
Serial Cmd: <K201,serial trigger
Default: ^] (corresponds to <GS>)
Options:
Any single 7-bit ASCII character, including control characters, except NUL
(00H), an existing host command character, or an on-line protocol char-
acter.
Note: Serial Data or Serial Data & Edge triggering mode must be enabled for Serial
Trigger Character to take effect.
7-12
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
and can only be sent when the trigger mode is set to Serial
character>
< >.
