Laser Setup
Laser On Position
Definition:
The Laser On Percentage of the full scan arc that the scan beam moves
through before the laser turns ON. For example, if set for 30, the laser
will be off during the first 30 percent of the scan.
Serial Cmd:
<K700,laser on/off status,laser framing
off position,laser power>
Default:
10
Options:
10 to 90
Laser Off Position
Definition:
Percentage of the full scan arc that the scan beam moves through before
the laser turns OFF.
Notes:
The combined values of Laser On Position and Laser Off Position can-
not exceed 100 percent, the total arc of one scan.
Laser Off Position must always exceed the value of Laser On Position
for an actual laser scan to take place.
Serial Cmd:
<K700,laser on/off status,laser framing status,laser on
off
position,laser power>
Default:
95
Options:
15 to 95
Laser Power
Usage:
Used to optimize read performance at different distances. Typically,
higher power is used at greater distances.
Definition:
Allows the user or calibration routine to select laser power setting.
Serial Cmd:
<K700,laser on/off status,laser framing status,laser on position,laser off
position,laser
Default:
High
Power (for low or medium density reader)
Options:
0 = Low
Low power ~ 0.6 mW
Medium power ~ 1.0 mW
High power ~ 1.5 mW
8-8
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
power>
1 = Medium
MS-860 Industrial Raster Reader User's Manual
status,laser on
position,laser
position,laser
2 = High
