RS-232/422 Host Port

Includes host port connections and host protocols.
Host Port Connections
Baud Rate, Host Port
Usage: Can be used to transfer data faster or to match host port settings.
Definition: The rate at which the reader and host transfer data back and forth.
Serial Cmd: <K100,baud
Default: 9600
Options: 0 = 600
1 = 1200
2 = 2400
Parity, Host Port
Usage: Only changed if necessary to match host setting.
Definition: An error detection routine in which one data bit in each character is set to
1 or 0 so that the total number of 1 bits in the data field is even or odd.
Serial Cmd: <K100,baud rate,parity,stop bits,data bits>
Default: Even
Options: 0 = None
Stop Bits, Host Port
Usage:
Only changed if necessary to match host setting.
Definition: One or two bits added to the end of each character to indicate the end of
the character.
Serial Cmd: <K100,baud
Default: One
Options: 0 = One
MS-860 Industrial Raster Reader User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
rate,parity,stop bits,data bits>
3 = 4800
4 = 9600
5 = 19.2K
1 = Even
rate,parity,stop bits,data bits>
1 = Two
Communications
6 = 38.4K
7 = 57.6K
8 = 115.2K
2 = Odd
6-3
