Output 1
Output Mode (Output 1)
Definition: Sets the condition in which the discrete output is de-activated.
Serial Cmd: <K810,output on,output state,pulse
Default: Pulse
Options: 0 = Pulse
1 = Latch Mode 1
Pulse
Definition: This is the default mode of operation in which the programmable output
is activated when the Output On condition has been met and held active
for the duration of the selected pulse width.
Latch Mode 1 (Unlatch on Input #1)
Definition: The programmable output goes active when the Output On condition is
met and will remain active until the state of input #1 changes from inac-
tive to active.
Important: To unlatch using the EZ Button the button's status must be
set to unlatch mode. (See
Latch Mode 2 (Unlatch Opposite Condition)
Definition: The programmable output goes active when the Output On condition is
met and will remain active until the opposite condition selected under
Output On occurs.
For example, if Noread is enabled under Output On, the programmable
output will go active upon a noread and remain active until the opposite
condition, a good read, occurs.
Latch Mode 3 (Unlatch Enter Read Cycle)
Definition: The programmable output goes active when the Output On condition
has been met and is held active until a new read cycle begins.
NOTE: All of the Output On modes are suppressed when any Output on Warning is
active for Output 1 (see
10-18
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
2 = Latch Mode 2
3 = Latch Mode 3
"Unlatch Outputs"
<K780> command).
MS-860 Industrial Raster Reader User's Manual
width,output mode>
on page 3-6.)
