Straight
Definition:
The scan line is set as a centered straight line during calibration. This is
equivalent to Top Position = Bottom Position = 127 in the raster com-
mand <K506,,127,127>.
No permanent change is made to the raster novram configuration
parameters.
Video Status
Definition:
Video status includes both Gain and Tracking.
When checked, Gain and Tracking settings
are fixed and is not calibrated.
When unchecked, they become part of the
calibration procedure.
Serial Cmd:
<K521,raster
tus,laser framing status,symbology detect>
Default:
Enabled
Options:
0 = Disabled
Scan Speed Status
Definition:
When checked, Scan Speed is fixed and is
not calibrated.
When unchecked, it becomes part of the
calibration procedure.
Serial Cmd:
<K521,raster options,video
tus,laser framing status,symbology detect>
Default:
Enabled
Options:
0 = Disabled
Note: Do not calibrate motor speed if using the calibration database.
MS-860 Industrial Raster Reader User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
options,video
status,scan speed status,laser power sta-
1 = Enabled
status,scan speed
1 = Enabled
Calibration
status,laser power sta-
4-7
