Microscan MS-860 User Manual page 211

Ordered Output
Ordered Output by Serial Command
Filter Index
Definition: The filter sequence number from 1 to 12
Serial Cmd: <K744,filter
holder character,data,decode direction,check database number>
Default: 0 (0 = disabled)
Options: Range 0 to 12
Symbology Type
Definition:
User-assigned symbology type that the reader will search for.
If a match is found, the reader then checks Length.
Serial Cmd: <K744,filter
holder character,data,decode direction,check database number>
Default: 0
Options: 0 = Any type
1 = I-2/5
2 = code 39
3 = code 128
4 = Codabar
Symbol Length
Definition: User-assigned symbol length that the reader will search for.
If the length is found, the reader then checks Wild Card.
Serial Cmd: <K744,filter index,symbology type,length,wildcard character,place-
holder character,data,decode direction,check database number>
Default: 0 (0 = any length)
Options: 0 to 128
13-12
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
index,symbology type,length,wildcard character,place-
index,symbology type,length,wildcard character,place-
5 = UPC
6 = PDF417
7 = EAN 128
8 = Code 93
9 = Pharmacode
MS-860 Industrial Raster Reader User's Manual
10 = RSS
11 = MicroPDF
12 = Composite
