Serial Configuration Commands
Complete List of Serial Configuration Commands
Input 1
Output 1
Trend Analysis (1)
Diagnostics (1)
Output 2
Trend Analysis (2)
Diagnostics (2)
Output 3
Trend Analysis (3)
Diagnostics (3)
Quality Output
Database Number Output
Symbol Position Output
Read Duration Output
Matchcode Type
Sequence Step
New Master Pin
Master Symbol
Database Size
Match Replace
Mismatch Replace
Enter/Delete Master Symbol
Data
Request Master Symbol Data <K231,?>[for all] or <K231,master symbol number?>
Power-on/Resets Counts
Hours Since Reset
Warning Messages
Laser High/Laser Low
High Temperature
Low Temperature
A-10
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
<K730,input mode,active state>
<K810,output on,active state,pulse width,output mode>
<K780,trend analysis mode,trigger evaluation period,number to output
on,decodes/trigger threshold>
<K790,over temperature,service threshold,[unused],laser current
high,laser current low,low temp>
<K811,output on,output state,pulse width,output mode>
<K781,trend analysis mode,number of triggers,number to output
on,decodes/trigger threshold>
<K791,over temperature,service threshold,unused,laser current
high,laser current low,low temp>
<K812,output on,output state,pulse width,output mode>
<K782,trend analysis mode,number of triggers,number to output
on,decodes/trigger threshold>
<K792,over temperature,service threshold,unused,laser current
high,laser current low,low temp>
<K704,quality output separator,decodes/trigger status,decode direction
status>
<K759,status,separator>
<K758,raster status,scan status,separator>
<K706,status,separator>
Matchcode
<K223,matchcode type,sequential matching,match start posi-
tion,match length,wild card character,sequence on noread,sequence on
mismatch>
<K228,sequence step>
<K225,status>
<K224,number of master symbols>
<K735,status,message>
<K735,status,message>
Master Symbol Database
<K231,master symbol number,master symbol data [no data will delete
current master symbol data]>
Diagnostics
<K406,?> returns: <K406,power-on,resets,power-on saves,custom
default saves> (read only)
<K407?> returns: <K407,hours,minutes>
<K400,warning message status,laser high status,laser low sta-
tus,novram/reset warning status>
<K411,laser high status,laser high message,laser low status,laser low
message>
<K402,high temperature status,high temperature message>
<K403,low temperature status,low temperature message>
