Request Master Symbol Data
Definition: Returns master symbol data for any enabled master symbols from 1 to
10.
For example, to request master symbol #5, enter <K231?,5>. The reader
transmits the following format: <K231,5,data>. If no master symbol
data available, the output will be: <M5/?>.
Serial Cmd: Send <K231?,master symbol
the current master symbol for a specific master symbol.
Returns all master symbols if no number is added before the question
mark.
Options: 1 to 10
Request All Master Symbols Data
Definition: Returns master symbol data for all enabled master symbols from 1 to 10.
Serial Cmd: Send <K231?>
Delete Master Symbol Data
Definition: Delete Master Symbol Data allows you to delete an enabled master
symbol.
Serial Cmd: Send <K231,master symbol
Options: 1 to 10
Store Next Symbol as Master Symbol
Definition: After you've set the size in the database, you can order the reader to
scan-in the next symbol as master symbol 1.
Serial Cmd: <Gmaster symbol
To store the next symbol scanned as master symbol #1 send:
<G1>. For all symbols numbers except 1, the number must be included.
Options: 1 to 10
MS-860 Industrial Raster Reader User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
number,master symbol data> to request
to request all current master symbols.
number,> to delete the master symbol.
number>
Utilities
<G> or
15-11
