Serial Command Beep Status
Important: ESP will not function whenever this command is enabled.
Usage: Used to audibly verify the acceptance and validity of a command.
Definition: Causes the reader to beep once whenever a K command is entered to
indicate that the command was accepted and processed.
Function: If an invalid command is entered, the reader beeps 5 times to indicate an
invalid entry. However, this does not necessarily mean that all data fields
have been entered incorrectly. Only one bad field needs to be found in
order to activate the 5 beep response.
Serial Cmd: <K701,serial command echo
trol/hex output>
Default: Disabled
Options: 0 = Disabled
Control/Hex Output
Usage: Useful for viewing settings with binary characters when using serial com-
mand on a terminal.
Definition: Determines the response to a Serial Command Echo or status request
command.
When set to Control, two characters are transmitted to represent a non-
displayable character. For example, a carriage return will be shown as the
two characters: ^M.
When set to Hex, the output is the hex character.
Serial Cmd: <K701,serial command echo status,serial command beep
trol/hex
Default: Control
Options: 0 = Control
MS-860 Industrial Raster Reader User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
status,serial command beep
1 = Enabled
output>
1 = Hex
I/O Parameters
status,con-
status,con-
10-13
