Operation of Database
Configuration Database Window
In ESP, when you click on the Database tab you will see the following:
Click once to select
the index row;
Double-click on
any row to make
specific changes in
popup dialog
Setting to any
number other than
zero will enable
(same as <K252>)
Number of times
all indexes in the
database are
attempted before
accepting the last
index
Time or number of
raster sweeps
before switching to
the next index
Time or number of
Receives database
raster sweeps to
settings from the
sequence indexes
reader
From ESP, you enable Database by setting Number of Active Database Indexes to
any number other than zero. The number chosen will cause that number of indexes in
the database above to turn blue.
You can make changes to any setting in any row simply by double-clicking and changing
the resulting popup dialog.
5-6
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Configuration parameters (all)
Loads the selected
index to current
Loads the Current
settings to selected
index
Saves database to
reader memory
Changes to settings in
the Current row are
dynamically updated
in the reader and ESP
settings
