Number of Filters
Definition: The number of filters that symbols will be compared against, up to the
specified number. For example, entering 7 means that filters #1 through
#7 will be enabled.
Serial Cmd: <K745,number of filters
Default: 0
Options: 0 to 12
Any number from 1 to 12 enables Output Filtering. A zero (0) disables
Output Filtering. The reader will not perform any filtered output.
For example:
<K745,1> enables Output Filters #1 setting.
<K745,3> enables Output Filters #1 to filter #3's setting.
<K745,0> disables all output filters. The reader will not perform any filtered output.
Examples to enable and setup filters 1 and 2:
Filter #1
Symbology type = Code 39, Length = disabled, Wildcard = '*', placeholder = '?',
data = "AB*" = 41422A
<K744,1,3,0,2A,3F,41422a>
Filter #2
Symbology type = Code 128, Length = 8, Wildcard = '*', placeholder = '?',
data = "NBC??FGH" = 4e42433f3f464748.
<K744,2,4,8,2A,3F,4e42433f3f464748>
<K745,2> enables Ordered Output. It also enables filter index1 and filter index2.
Let's say we have four symbols, "NBCXYFGH", "NBDXYFGH", "123XYZ", "ABCDE". The
reader will registered two good reads only and transmit the following:"ABCDE", "NBCX-
YFGH".
MS-860 Industrial Raster Reader User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
involved>
Output Format
13-15
