Electrical Specifications
Additional Isolated Output Circuit Examples
Isolated Reader
Power +
Scanner
Outputs (+)
Output
Outputs (–)
Power ground
A-6
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Secondary Relay
Isolated Reader
1 to 28 V
RELAY
Scanner
Output
MS-860 Industrial Raster Reader User's Manual
PLC
Power +
V
PLC
Outputs (+)
Input
PLC
Outputs (–)
GND
Power ground
