I/O Parameters by Serial Command

Symbol Data Output
Noread Message
Bad Symbol Message
No Symbol Message
Output Indicators
Beeper
Serial Verification
Input 1
Output 1
Trend Analysis (1)
Diagnostics (1)
Output 2
Trend Analysis (2)
Diagnostics (2)
Output 3
Trend Analysis (3)
Diagnostics (3)
Quality Output
Database Number Output
Symbol Position Output
Read Duration Output
MS-860 Industrial Raster Reader User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
I-O Parameters
<K705,symbol data output mode,when to output>
<K714,status,noread message>
<K715,bad symbol status,bad symbol message>
<K716,no symbol status,no symbol message>
<K750,green flash mode,[unused],green flash duration>
<K702,beeper output>
<K701,serial command echo status,serial command beep status,con-
trol/hex output>
<K730,input mode,active state>
<K810,output on,active state,pulse width,output mode>
<K780,trend analysis mode,trigger evaluation period,number to output
on,decodes/trigger threshold>
<K790,over temperature,service threshold,[unused],laser current
high,laser current low,low temp>
<K811,output on,output state,pulse width,output mode>
<K781,trend analysis mode,number of triggers,number to output
on,decodes/trigger threshold>
<K791,over temperature,service threshold,unused,laser current
high,laser current low,low temp>
<K812,output on,output state,pulse width,output mode>
<K782,trend analysis mode,number of triggers,number to output
on,decodes/trigger threshold>
<K792,over temperature,service threshold,unused,laser current
high,laser current low,low temp>
<K704,quality output separator,decodes/trigger status,decode direction
status>
<K759,status,separator>
<K758,raster status,scan status,separator>
<K706,status,separator>
I/O Parameters
10-3
