No Symbol Message
Note: No Symbol Message does not apply to multisymbol operations.
Usage:
Useful in determining if an object has an attached symbol.
Definition:
When enabled, sends a message to the host whenever an object is
detected but no symbol is detected.
The No Symbol output is tied to the transition counter. If during a read
cycle no symbol is decoded and the required setting for the Transition
Sample Threshold is NOT met, a user defined message will be sent to
the host. See
Note: AGC (page 7-19) must be disabled when this feature is used.
No Symbol Status
Serial Cmd:
<K716,no symbol
Default:
Disabled
Options:
0 = Disabled
No Symbol Message
Serial Cmd:
<K716,no symbol
Default:
NO_SYMBOL
Options:
Up to 128 ASCII characters (except NUL)
MS-860 Industrial Raster Reader User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
"Transition Counter"
on page 7-21.
status,no symbol message>
1 = Enabled
status,no symbol
message>
I/O Parameters
10-9
