Output 2
Serial Cmd:
<K811,output on,output state,pulse width,output mode>
Output 2 has the same parameters and default settings as Output 1.
Trend Analysis (output 2)
Definition:
Applies trend analysis settings to Output 2.
Serial Cmd:
<K781,trend analysis mode,number of triggers,number to output
on,decodes/trigger threshold>
Trend Analysis to Output 2 has the same parameters and default settings as Trend
Analysis to Output 1.
Diagnostic Warnings (output 2)
Definition:
Applies diagnostic warnings to Output 2.
Serial Cmd:
<K791,over temperature,service threshold,unused,laser current
high,laser current low,low temp>
Diagnostic Warnings to Output 2 has the same parameters and default settings as
Diagnostic Warnings to Output 1.
MS-860 Industrial Raster Reader User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
I/O Parameters
10-23
