Extraction Mode

Extraction Mode

Usage: Useful in scanning symbols in which only a portion or portions of the
symbol data needs to be transmitted and sorted.
Definition: Selects a portion of the symbol data to be transmitted and ignores the
rest.
Extraction by ESP
1. Click Read
Symbol. This
will display in
the current
symbol data Reader test label 1-1-06
under Original.
Reader
4. Click
additional extractions and
insertions.
After selecting and entering the extracted portion or portions of a symbol, you can proceed
to Insertion mode where user-selectable ASCII text can be inserted. You can perform up
to 100 instances of extraction and insertion for all symbols being scanned in the read cycle.
See "Multisymbol Output Format Status"
13-4
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
2. Select text to be
3. Click
The extracted selected text
will appear in this field.
Apply or proceed with
5. Click Test.
Output Format Extraction
on page 13-8.
MS-860 Industrial Raster Reader User's Manual
extracted.
Extract
Note: When you click Apply, Symbol
#1 in Symbol Output Format Status
window will automatically be enabled.
