Match (Green Flash)
Green flash LEDs will flash for less than 1 second when a match condition is met. If mul-
tisymbol is enabled, then green flash LEDs will illuminate only if all symbols qualify as a
match. If matchcode is disabled, then this mode will activate the LED's on a good read.
Mismatch (Green Flash)
Same as On Match except it illuminates on a mismatch.
Green Flash Duration
Usage:
A visual verification that a good read has occurred.
Definition:
When a good read occurs, the Green flash LED's will illuminate and stay
on for the time set for the Green Flash Duration value.
Serial Cmd:
<K750,green flash
Default:
100
(1 second)
Options:
0 to 65535 (in 10mS increments)
Beeper Output Condition
Usage:
Provides an audible verification that either a good read, noread or EZ
Button action has occurred.
Definition:
A beep is emitted either after each good read of a symbol or after each
noread, according to the Beeper Output Condition selection.
Note: Beeper will also sound if any of the following occur:
• the reader is defaulted a send/save command from ESP or an Exit
command from any embedded menu.
• a <Z>, <Zp>, <Zd>, or
Serial Cmd:
<K702,beeper
Default:
On Good Read
Options:
0 = Disabled
MS-860 Industrial Raster Reader User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
mode,[unused],green flash
<K,1>
command is sent
output>
1 = On Good Read
I/O Parameters
duration>
2 = On Noread
10-11
