Symbol Data Output

Symbol Data Output

Usage: Useful when the host needs symbol data only under certain conditions.
Definition: Defines the conditions under which decoded symbols are transmitted to
the host.
Symbol Data Output Status
Serial Cmd: <K705,symbol output
Default: Good Read
Options: 0 = Disabled
1 = Match
Note: If set to Match or Mismatch, Symbol Output Status will not take effect unless
Matchcode Type is enabled and a master symbol is loaded into memory.
Disabled
Usage: Useful when an application only needs to use the discrete outputs and
can allow the reader to do the decision-making. When Disabled, the host
does not need the symbol data and the communication lines are used
only for setup and status checks.
Definition: When set to Disabled, the reader will not transmit any data that is gen-
erated during a read cycle (symbols, noreads, etc.).
Match
Usage: Match is used in an application that requires specific symbol information
and needs to sort, route or verify based on matching the specific symbol
data.
Definition: When set to Match, the reader transmits symbol data whenever a sym-
bol matches a master symbol. However, if Matchcode Type is Disabled,
it transmits on any good read.
Note: A noread can still be transmitted if Enabled.
Mismatch
Usage: Mismatch is typically used as a flag within the host system to prevent an
item from being routed in the wrong container.
Definition: With Mismatch
symbol data information does NOT match the master symbol.
Note: A noread can still be transmitted if enabled.
10-4
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
status,when to output>
2 = Mismatch
3 = Good Read
enabled, the reader transmits symbol data whenever the
