Read Duration Output
Read Duration Output
Definition:
When enabled the duration (in milliseconds) from when the read cycle
started until the symbol data is output is appended to the data with a
separator. It is important to note that when in level mode if the user
wishes to measure the entire length of the trigger pulse the user needs to
set the When to Output Symbol Data to End of Read Cycle. This will pre-
vent the read duration from being shorter than the entire read cycle in
the event you qualify the symbol requirements for output before the trig-
ger becomes inactive. This output has the capability of measuring over
49 days worth of duration, if exceeded the message "OVERFLOW" will be
output in place of the duration.
Status
Serial Cmd:
<K706,status,separator>
Default:
Disabled
Options:
0 = Disabled
Separator
Definition:
Any combination of ASCII characters can be defined as the separator.
Serial Cmd:
<K706,status,separator>
Default:
(Space)
Options:
Any ASCII character.
Separator can be set to any ASCII characters except NULL, <, >, and
10-30
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
1 = Enabled
MS-860 Industrial Raster Reader User's Manual
,
.
