Trend Analysis
Tracks the occurrences and frequency of mismatches, noreads, and the number of
decodes per trigger and output the results to output 1.
Disabled
No output.
Diagnostic Warning
Activates output 1 when a diagnostic warning condition is met. When enabled the Out-
put State and Pulse Width settings
put. The output will remain active as long as one of the diagnostic warning conditions
persists. The output will go inactive whenever the warning condition no longer exists.
The output remains active as long as one of the diagnostic conditions is met.
In Read Cycle
Output is active during the read cycle.
Output State (Output 1)
Definition:
Sets the output state of the discrete output.
Serial Cmd: <K810,output
Default: Normally Open
Options: 0 = Normally Open
Pulse Width (Output 1)
Definition: Sets the time in 10mS increments that the discrete output remains active.
Serial Cmd: <K810,output on,output
Default: 50 mS (0.05 seconds)
Options: 1 to 65535 (0.01 to 65.535 seconds)
