Microscan MS-2 Configuration Manual

MS-2
CCD Reader
Configuration Guide

Hardware Required

Item Description
1 MS-2 CCD Reader
2 MS-Connect 210 Connectivity Box
3 IC-332 Voltage Converter (to 10-28V)
4 IB-3PC Interface
5 IB-131 Interface Box
6 Object Detector (Photo Sensor, Visible, NPN, Dark On)
7 Object Detector (Photo Sensor, Visible, NPN, Light On)
8 Power Supply (90-264 VAC, 24VDC, USA/Euro plug)
9 Power Supply (90-264 VAC, +5VDC)
10 Host Cable (MS-Connect 210 to Host, User-stripped to 9-pin)
11 Reader Cable (Reader to MS-Connect 210, 6')
12 Communication Cable (IB-131 to Host, 6')
13 Communication Cable (IB-3PC to Host, 6 ft.)
Configurations
Standalone (5V)
4
13
Keyboard Wedge (5V)
4
Copyright ©2016 Microscan Systems, Inc.
Standalone (10-28V)
9
3
12
1
8
Standalone with MS-Connect 210 (10-28V)
1
11
3
USB (5V)
1
Important: USB
models support USB
5
1.1 Keyboard Mode
only. Virtual COM
serial emulation is
not supported.
6
2
10
7
8
1
Part Number
FIS-0002-000XG
FIS-0210-000XG
FIS-0001-0035G
FIS-0001-0030G
99-000018-01
99-000017-01
99-000017-02
97-000012-02
97-000011-01
61-000105-01
61-000127-01
61-300026-03
61-000010-02
1
P/N 83-210059 Rev C
