Input

Usage: For example, an application is setup so that a mismatch stops the pro-
duction line by using outputs in a latch mode (see
put 1)"
input pin so that when pressed, it unlatches the output, allowing the line
to resume operations.
Definition:
A programmable, discrete input used to reset counters, outputs or control
optoelectrical settings.
Serial Cmd: K730,input
<
Default: Disabled
Options: 0 = Disabled
Disabled
Definition: When set to Disabled there is no effect on operation.
Reset Counts
Usage: Primarily used in test mode. Can also be used to reset counters daily.
Definition: When set to Reset Counts, a transition to the active state of the input
will cause the reader to reset the internal counters (See
page 15-3).
Unlatch Output
Definition: This setting is used in combination with any of the three discrete outputs
that are in Unlatch Mode 1 (see
#1)" on page 10-18). A transition to the active state will clear any of the
three outputs that were previously latched.
Active State
Definition: Determines the state at which inputs will react to input signals.
Serial Cmd: K730,input
<
Default: Active Closed
Options: 0 = Active Open
When set to Active Closed, the input function is activated when the input state is
energized. When set to Active Open, the input function is activated when the input
state is de-energized.
MS-860 Industrial Raster Reader User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
on page 10-18). A push button switch can be connected to the
mode,active state>
1 = Reset Counts
mode,active state>
1 = Active Closed
I/O Parameters
"Output Mode (Out-
2 = Unlatch Output
"Read Rate"
"Latch Mode 1 (Unlatch on Input
on
10-15
