Raster Setup
You can setup and make changes to the reader's raster parameters in ESP in the Read
Cycle menu, the Calibration menu, or the Raster/Laser menu (preferred).
Usage:
Raster scanning is useful when symbols vary in placement and a single
scan line cannot be counted on to cross the symbol, and for reading
stacked symbologies such as PDF417.
Definition:
The user can enable raster scanning and adjust the raster sweep limits
and the sweep rate.
Raster Status
Definition:
When disabled, the raster mirror will park at the top of the raster sweep.
Serial Cmd:
<K506,raster
on/off>
Default:
Enabled
Options:
0 = Disabled
Note: Raster sweeps are only counted during a read cycle (continuous, triggered, and
read rate). Raster sweeps are NOT counted when the raster motor is parked, disabled,
set to straight line operation (top and bottom are equal), or when performing a self-cal-
ibration.
MS-860 Industrial Raster Reader User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
status,top offset,bottom offset,raster sweep rate,read cycle
1 = Enabled
Raster/Laser
8-3
