Bad Symbol Message

Bad Symbol Message

Note: Bad Symbol Message does not apply to multisymbol operations.
Usage: Useful in verifying the presence of a symbol that has not been decoded.
Definition: When enabled, a message is sent to the host when a symbol is detected
but not decoded. See
The Bad Symbol output is tied to the transition counter. If during a read
cycle no symbol is decoded and the required setting for the Transition
Sample Threshold is met, a user defined message will be sent to the
host.
Note: AGC (page 7-19) must be disabled when this feature is used.
Bad Symbol Status
Serial Cmd: <K715,bad symbol
Default: Disabled
Options: 0 = Disabled
Bad Symbol Message
Serial Cmd: <K715,bad symbol
Default: BAD_SYMBOL
Options: Up to 128 ASCII characters (except NUL)
The Bad Symbol output is tied to the transition counter. If during a read
cycle no symbol is decoded and the required setting for the Transition
Sample Threshold is met, a user defined message will be sent to the
host.
10-8
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
"Transition Counter"
status,bad symbol message>
1 = Enabled
status,bad symbol message>
MS-860 Industrial Raster Reader User's Manual
on page 7-21.
