Mismatch Replace - Microscan MS-860 User Manual

Mismatch Replace

Status
Usage: Useful when a user-defined message is needed in place of the mismatch
code message.
Definition: When enabled, the Mismatch Replace message is output instead of the
bar code data when a mismatch occurs.
Serial Cmd: <K736,status,message>
Default: Disabled
Options: 0 = Disabled
Note: In addition to enabling Mismatch Replace, you will need to have done the following:
1. Enable a triggered read cycle in
2. Enable "Matchcode Type"
"Symbol Data Output"
3. Enable
Mismatch Replacement Message
Definition: Creates the ASCII string that will replace the configured master symbol
data that is read whenever a mismatch occurs.
Serial Cmd: <K736,status,message>
Default: MATCH
Options:
1 to 128 valid ASCII characters
MS-860 Industrial Raster Reader User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
1 = Enabled
"Trigger" on page 7-6.
on page 11-4.
on page 10-4.
Matchcode
11-13
