Read Cycle by Serial Command

Multisymbol
Trigger Mode
External Trigger State
Serial Trigger Character
Start Serial Trigger Character <K229,start trigger character>
Stop Serial Trigger Character <K230,stop trigger character>
End of Read Cycle
Decodes Before Output
Database Setup
Database Operation
Database Mode
Save Current to Database
Load Current from Database
Tracking
Scan Speed
Automatic Gain Control
Symbol Detect Status
Maximum Element
MS-860 Industrial Raster Reader User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Read Cycle
<K222,number of symbols,multisymbol separator>
<K200,trigger mode,trigger filter duration>
<K202,external trigger state>
<K201,serial trigger character>
<K220,end of read cycle mode,read cycle timeout>
<K221,number before output,decodes before output mode>
Configuration Database Control
<K253,index,gain,AGC mode,tracking,raster top,raster bottom,raster
speed,laser framing status,laser on position,laser off position,laser
power,background color>
<K252,number of active indexes,database cycles>
<K254,mode,count/time>
<K253+,database index>
<K253-,database index>
Reader Setup
<K520,tracking>
<K500,scan speed>
<K504,gain level,AGC sampling,AGC min,AGC max>
<K505,symbol detect status,transition counter>
<K502,maximum element>
Read Cycle
7-3
