13-02 Stop Event
Option:
[18] Reversing
[19] Warning
[20] Alarm (trip)
4 4
[21] Alarm (trip
lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input
DI18
[34] Digital input
DI19
[35] Digital input
DI27
[36] Digital input
DI29
[39] Start command
[40] Drive stopped
*
[42] Auto Reset Trip This event is TRUE if the frequency
70
®
VLT DriveMotor FCP 106 and FCM 106 Programming Guide
Function:
See parameter 13-01 Start Event for
further description.
See parameter 13-01 Start Event for
further description.
See parameter 13-01 Start Event for
further description.
See parameter 13-01 Start Event for
further description.
Use the result of comparator 0 in the
logic rule.
Use the result of comparator 1 in the
logic rule.
Use the result of comparator 2 in the
logic rule.
Use the result of comparator 3 in the
logic rule.
Use the result of logic rule 0 in the logic
rule.
Use the result of logic rule 1 in the logic
rule.
Use the result of logic rule 2 in the logic
rule.
Use the result of logic rule 3 in the logic
rule.
Use the result of timer 0 in the logic rule.
Use the result of timer 1 in the logic rule.
Use the result of timer 2 in the logic rule.
Use the value of DI18 in the logic rule
(High = TRUE).
Use the value of DI27 in the logic rule
(High = TRUE).
Use the value of DI29 in the logic rule
(High = TRUE).
This event is TRUE if the frequency
converter is started by any means (either
via digital input, fieldbus or other).
This event is TRUE if the frequency
converter is stopped or coasted by any
means (either via digital input, fieldbus or
other).
converter is tripped (but not trip-locked)
and an Automatic Reset is issued.
MG03N102 - Rev. 2013-12-02
13-02 Stop Event
Option: Function:
[50] Comparator 4 Use the result of comparator 4 in the
logic rule.
[51] Comparator 5 Use the result of comparator 5 in the
logic rule.
[60] Logic rule 4 Use the result of logic rule 4 in the logic
rule.
[61] Logic rule 5 Use the result of logic rule 5 in the logic
rule.
[70] SL Time-out 3 Use the result of timer 3 in the logic rule.
[71] SL Time-out 4 Use the result of timer 4 in the logic rule.
[72] SL Time-out 5 Use the result of timer 5 in the logic rule.
[73] SL Time-out 6 Use the result of timer 6 in the logic rule.
[74] SL Time-out 7 Use the result of timer 7 in the logic rule.
[83] Broken Belt A broken belt condition has been
detected. This function must be enabled
in parameter 22-60 Broken Belt Function.
13-03 Reset SLC
Option: Function:
[0] Do not reset Retains programmed settings in all group
*
SLC 13 parameters (13-** Smart Logic).
[1] Reset SLC Resets all group 13 parameters (13-** Smart
Logic) to default settings.
4.9.3 13-1* Comparators
Comparators are used for comparing continuous variables
(i.e. output frequency, output current, analog input etc.) to
fixed preset values.
Par. 13-11
Comparator Operator
Par. 13-10
Comparator Operand
=
TRUE longer than.
Par. 13-12
Comparator Value . . .
. . .
Illustration 4.16 Comparators
In addition, there are digital values that are compared to
fixed time values. See explanation in
parameter 13-10 Comparator Operand. Comparators are
evaluated once in each scan interval. Use the result (TRUE
or FALSE) directly. All parameters in this parameter group
are array parameters with index 0 to 5. Select index 0 to
programme Comparator 0, select index 1 to programme
Comparator 1, and so on.
