Parameter Description

3.13 Main Menu - Data Readouts - Group 16

16-00 Control Word
Range:
0 [0 - 65535 ] View the Control word sent from the
*
3 3
16-01 Reference [Unit]
Range:
0 ReferenceFeed-
backUnit
*
16-02 Reference [%]
Range:
0 % [-200 - 200
*
%]
16-03 Status Word
Range:
0 [0 - 65535 ] View the Status word sent from the frequency
*
16-05 Main Actual Value [%]
Range:
0 % [-100 - 100 %] View the two-byte word sent with the
*
16-09 Custom Readout
Range:
0 CustomRea-
doutUnit
*
3.13.1 16-1* Motor Status
16-10 Power [kW]
Range:
0 kW [0 -
*
1000 kW]
104
VLT
Function:
frequency converter via the serial communi-
cation port in hex code.
Function:
[-999999 - 999999 View the present
ReferenceFeed- reference value applied
backUnit] on impulse or analog
basis in the unit
resulting from the
configuration selected
in 1-00 Configuration
Mode (Hz, Nm or RPM).
Function:
View the total reference. The total
reference is the sum of digital, analog,
preset, bus, and freeze references, plus
catch-up and slow-down.
Function:
converter via the serial communication port in
hex code.
Function:
Status word to the bus Master reporting
the Main Actual Value.
Function:
[-999999.99 - View the user-defined
999999.99 readouts as defined in
CustomRea- 0-30 Custom Readout Unit,
doutUnit] 0-31 Custom Readout Min
Value and 0-32 Custom
Readout Max Value.
Function:
Displays motor power in kW. The value shown
is calculated on the basis of the actual motor
voltage and motor current. The value is
MG16H102 - VLT
®
Refrigeration Drive Programming Guide
16-10 Power [kW]
Range:
16-11 Power [hp]
Range:
0 hp [0 - 1000
*
hp]
16-12 Motor Voltage
Range:
0 V [0 - 6000 V] View the motor voltage, a calculated value
*
16-13 Frequency
Range:
0 Hz [0 - 6500 Hz] View the motor frequency, without
*
16-14 Motor current
Range:
0 A [0 - 1856
*
A]
16-15 Frequency [%]
Range:
0 % [-100 -
*
100 %]
®
is a registered Danfoss trademark
Function:
filtered, and therefore approx. 30 ms may pass
from when an input value changes to when
the data read-out values change. The
resolution of read-out value on fieldbus is in
10 W steps.
Function:
View the motor power in HP. The value shown
is calculated on the basis of the actual motor
voltage and motor current. The value is
filtered, and therefore approximately 30 ms
may pass from when an input value changes
to when the data read-out values change.
Function:
used for controlling the motor.
Function:
resonance dampening.
Function:
View the motor current measured as a mean
value, I . The value is filtered, and thus
RMS
approximately 30 ms may pass from when an
input value changes to when the data read-
out values change.
Function:
View a two-byte word reporting the actual
motor frequency (without resonance
dampening) as a percentage (scale 0000-4000
Hex) of 4-19 Max Output Frequency. Set
9-16 PCD Read Configuration index 1 to send it
with the Status Word instead of the MAV.
