Parameter Lists

6.1.7 5-** Digital In/Out

Par. No. # Parameter description
5-0* Digital I/O mode
5-00 Digital Input Mode
5-03 Digital Input 29 Mode
5-1* Digital Inputs
5-10 Terminal 18 Digital Input
5-11 Terminal 19 Digital Input
5-12 Terminal 27 Digital Input
5-13 Terminal 29 Digital Input
5-3* Digital Outputs
5-34 On Delay, Digital Output
5-35 Off Delay, Digital Output
5-4* Relays
5-40 Function Relay
5-41 On Delay, Relay
5-42 Off Delay, Relay
5-5* Pulse Input
5-50 Term. 29 Low Frequency
5-51 Term. 29 High Frequency
5-52 Term. 29 Low Ref./Feedb. Value
5-53 Term. 29 High Ref./Feedb. Value
5-9* Bus Controlled
5-90 Digital & Relay Bus Control
®
VLT DriveMotor FCP 106 and FCM 106 Programming Guide
Default value
[0] PNP
[0] PNP
[8] Start
[0] No operation
ExpressionLimit
[14] Jog
0.01 s
0.01 s
ExpressionLimit
0.01 s
0.01 s
4 Hz
32000 Hz
0 N/A
50 N/A
0 N/A
MG03N102 - Rev. 2013-12-02
2-set-up Change Conver-
during sion
operation index
1 set-up FALSE
1 set-up FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Type
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
6
-2 uint16
-2 uint16
- Uint8
-2 Uint16
-2 Uint16
0 Uint32
0 Uint32
-3 Int32
-3 Int32
0 Uint32
103
6
