Reference/Ramps; Limits/Warnings - Danfoss VLT DriveMotor FCP 106 Programming Manual

Parameter Lists

6.1.5 3-** Reference/Ramps

Par. No. # Parameter description
3-0* Reference Limits
3-02 Minimum Reference
3-03 Maximum Reference
3-1* References
3-10 Preset Reference
3-11 Jog Speed [Hz]
3-14 Preset Relative Reference
3-15 Reference 1 Source
3-16 Reference 2 Source
6 6
3-17 Reference 3 Source
3-4* Ramp 1
3-41 Ramp 1 Ramp Up Time
3-42 Ramp 1 Ramp Down Time
3-5* Ramp 2
3-51 Ramp 2 Ramp Up Time
3-52 Ramp 2 Ramp Down Time
3-8* Other Ramps
3-80 Jog Ramp Time
3-81 Quick Stop Ramp Time

6.1.6 4-** Limits/Warnings

Par. No. # Parameter description
4-1* Motor Limits
4-10 Motor Speed Direction
4-12 Motor Speed Low Limit [Hz]
4-14 Motor Speed High Limit [Hz]
4-18 Current Limit
4-19 Max Output Frequency
4-4* Adj. Warnings 2
4-40 Warning Freq. Low
4-41 Warning Freq. High
4-5* Adj. Warnings
4-50 Warning Current Low
4-51 Warning Current High
4-54 Warning Reference Low
4-55 Warning Reference High
4-56 Warning Feedback Low
4-57 Warning Feedback High
4-58 Missing Motor Phase Function
4-6* Speed Bypass
4-61 Bypass Speed From [Hz]
4-63 Bypass Speed To [Hz]
4-64 Semi-Auto Bypass Set-up
102
®
VLT DriveMotor FCP 106 and FCM 106 Programming Guide
Default value
0 ReferenceFeedbackUnit
ExpressionLimit
0 %
5 Hz
0 %
[1] Analog in 53
[2] Analog in 54
[11] Local bus reference
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
Default value
[2] Both directions
0 Hz
65 Hz
110 %
ExpressionLimit
ExpressionLimit
ExpressionLimit
0 A
ExpressionLimit
-4999 N/A
4999 N/A
-4999 ProcessCtrlUnit
4999 ProcessCtrlUnit
[1] On
0 Hz
0 Hz
[0] Off
MG03N102 - Rev. 2013-12-02
2-set-up Change Conver-
during sion
operation index
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
2-set-up Change Conver-
during sion
operation index
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Type
-3 Int32
-3 Int32
-2 Int16
-1 Uint16
-2 Int16
- Uint8
- Uint8
- Uint8
-2 Uint32
-2 Uint32
-2 Uint32
-2 Uint32
-2 Uint32
-2 Uint32
Type
- Uint8
-1 Uint16
-1 Uint16
0 Uint16
-1 Uint16
-1 uint16
-1 uint16
-2 Uint32
-2 Uint32
-3 Int32
-3 Int32
-3 Int32
-3 Int32
- Uint8
-1 Uint16
-1 Uint16
- Uint8
