1 Introduction

1.1 Purpose of the Manual

The Programming Guide provides information required for
commissioning and programming the frequency converter,
including complete parameter descriptions.

1.2 Additional Resources

Literature available:
•
®
VLT DriveMotor FCP 106 and FCM 106 Operating
Instructions, for information required to install and
commission the frequency converter.
•
®
VLT DriveMotor FCP 106 and FCM 106 Design
Guide, provides information required for
integration of the frequency converter into a
diversity of applications.
•
®
VLT DriveMotor FCP 106 and FCM 106
Programming Guide, for how to program the unit,
including complete parameter descriptions.
•
®
VLT LCP Instruction, for operation of the local
control panel (LCP).
•
®
VLT LOP Instruction, for operation of the local
operation pad (LOP).
•
Modbus RTU Operating Instructions, VLT
DriveMotor FCP 106 and FCM 106 BACnet Operating
®
Instructions and VLT
106 Metasys Operating Instructions, for information
required for controlling, monitoring, and
programming the frequency converter.
•
PC-based Configuration Tool MCT 10, enables
configuration of the frequency converter from a
Windows™ based PC environment.
•
®
Danfoss VLT Energy Box software, for energy
calculation in HVAC applications.
Technical literature and approvals are available online at
www.danfoss.com/BusinessAreas/DrivesSolutions/Documen-
tations/Technical+Documentation.
®
Danfoss VLT Energy Box software is available at
www.danfoss.com/BusinessAreas/DrivesSolutions, PC software
download area.

1.3 Document and Software Version

This manual is regularly reviewed and updated. All
suggestions for improvement are welcome. Table 1.1 shows
the document version and the corresponding software
version.
In the frequency converter, read the software version in
parameter 15-43 Software Version.
®
VLT DriveMotor FCP 106 and FCM 106 Programming Guide
®
DriveMotor FCP 106 and FCM
MG03N102 - Rev. 2013-12-02
Edition Remarks
MG03N1xx New document
Table 1.1 Document and Software Version

1.4 Copyright

This publication contains information proprietary to
Danfoss. By accepting and using this manual the user
agrees that the information contained herein is used solely
for operating equipment from Danfoss or equipment from
other vendors if such equipment is intended for communi-
cation with Danfoss equipment over a serial
communication link. This publication is protected under
the Copyright laws of Denmark and most other countries.
Danfoss does not warrant that a software program
produced according to the guidelines provided in this
manual functions properly in every physical, hardware or
software environment.
Although Danfoss has tested and reviewed the documen-
tation within this manual, Danfoss makes no warranty or
representation, neither expressed nor implied, with respect
to this documentation, including its quality, performance,
or fitness for a particular purpose.
In no event shall Danfoss be liable for direct, indirect,
special, incidental, or consequential damages arising out of
the use, or the inability to use information contained in
this manual, even if advised of the possibility of such
damages. In particular, Danfoss is not responsible for any
costs, including but not limited to those incurred as a
result of lost profits or revenue, loss or damage of
equipment, loss of computer programs, loss of data, the
costs to substitute these, or any claims by third parties.
Danfoss reserves the right to revise this publication at any
time and to make changes to its contents without prior
notice or any obligation to notify former or present users
of such revisions or changes.

1.5 Symbols, Abbreviations and Definitions

The following symbols are used in this manual.
WARNING
Indicates a potentially hazardous situation which could
result in death or serious injury.
