3.12 Main Menu - Data Readouts - Group 16

3.12.1 16-0* General Status

3 3
16-00 Control Word
Range:
0 [0 - 65535 ] View the control word sent from the
*
Bit number
15 14 13 12
Bit Bit = 0
00 Preset reference choice lsb
01 Preset reference choice second bit of
preset references
02 DC brake
03 Coasting
04 Quick stop
05 Freeze output
06 Ramp stop
07 No function
08 No function
09 Ramp 1
10 Data not valid
11 Relay_A not active
12 Relay_B not active
13 Choice of Set-up lsb
14 No function
15 No function
Table 3.8 Control Word
16-01 Reference [Unit]
Range:
0 ReferenceFeed-
backUnit
*
16-02 Reference [%]
Range:
0 % [-200 - 200 %]
*
3-54
VLT
Function:
adjustable frequency drive via the serial
communication port in hex code.
11 10 9 8 7 6 5 4 3 2 1 0
Bit = 1
Ramp
Enable
Ramp
Ramp
Start
Reset
Jog
Ramp 2
Valid
Relay_A activated
Relay_B activated
No function
Reversing
Function:
[-4999 - 4999 View the present
ReferenceFeed- reference value applied
backUnit] on impulse or analog
basis in the unit
resulting from the
configuration selected
in 1-00 Configuration
Mode (Hz).
Function:
MG18B222 - VLT
®
HVAC Basic Drive Programming Guide
16-03 Status Word
Range:
0 [0 - 65535 ] View the status word sent from the adjustable
*
Bit number
15 14 13
Bit Bit = 0
00 Control not ready
01 VLT not ready
02 Coasting
03 No fault
04 No warning
05 Reserved
06 No trip lock
07 No warning
Speed ≠ ref.
08
09 Local control
10 Out of speed range
11 Not running
12 No function
13 Voltage OK
14 Current OK
15 Temperature OK
Table 3.9 Status Word
16-05 Main Actual Value [%]
Range:
0 %
*
16-09 Custom Readout
Range:
0 CustomRea-
doutUnit
*

3.12.2 16-1* Motor Status

16-10 Power [kW]
Range:
0 kW [0 - 1000 kW] Displays DC link power in kW. The value
*
®
is a registered Danfoss trademark
Function:
frequency drive via the serial communication
port in hex code.
12 11 10 9 8 7 6 5 4 3 2 1 0
Bit = 1
Ready
Ready
Enable
Trip
Warning
Trip lock
Warning
Speed = ref.
Bus control
Frequency OK
Running
No function
Above limit
Above limit
Above limit
Function:
[-200 - 200 %]
Function:
[0 - 9999 View the user-defined
CustomRea- readouts as defined in
doutUnit] 0-30 Custom Readout Unit,
0-31 Custom Readout Min
Value and 0-32 Custom
Readout Max Value. Custom
Readout
Function:
shown is calculated on the basis of the
actual motor voltage and motor current.
