Parameters
5-40 Function Relay
Array (Relay 1 [0], Relay 2 [1])
Select options to define the function of the relays.
The selection of each mechanical relay is realised in an array
parameter.
Default values for 5-40 Function Relay:
When 0-03 Regional Settings is set to [0] International, the default
value of Relay1 is 'Alarm', and default value of Relay2 is 'Drive
Running'.
When 0-03 Regional Settings is set to [1] North America, the
default value of Relay1 is 'No Alarm', and default value of Relay2
is 'Drive Running'.
Option: Function:
[63] Comparator 3 See parameter group 13-1*. If
Comparator 3 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[64] Comparator 4 See parameter group 13-1*. If
Comparator 4 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[65] Comparator 5 See parameter group 13-1*. If
Comparator 5 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[70] Logic rule 0 See parameter group 13-4*. If Logic Rule
0 is evaluated as TRUE, the output will go
high. Otherwise, it will be low.
[71] Logic rule 1 See parameter group 13-4*. If Logic Rule
1 is evaluated as TRUE, the output goes
high. Otherwise, it is low.
[72] Logic rule 2 See parameter group 13-4*. If Logic Rule
2 is evaluated as TRUE, the output goes
high. Otherwise, it is low.
[73] Logic rule 3 See parameter group 13-4*. If Logic Rule
3 is evaluated as TRUE, the output goes
high. Otherwise, it is low.
[74] Logic rule 4 See parameter group 13-4*. If Logic Rule
4 is evaluated as TRUE, the output goes
high. Otherwise, it is low.
[75] Logic rule 5 See parameter group 13-4*. If Logic Rule
5 is evaluated as TRUE, the output goes
high. Otherwise, it is low.
[80] SL digital See parameter 13-52 SL Controller Action.
output A The input will go high whenever the
Smart Logic Action [38] Set dig. out. A
high is executed. The input goes low
whenever the Smart Logic [32] Action Set
dig. out. A low is executed.
[81] SL digital See parameter 13-52 SL Controller Action.
output B The input goes high whenever the Smart
Logic Action [39] Set dig. out. B high is
executed. The input goes low whenever
the Smart Logic [33] Action Set dig. out. B
low is executed.
®
VLT DriveMotor FCP 106 and FCM 106 Programming Guide
5-40 Function Relay
Array (Relay 1 [0], Relay 2 [1])
Select options to define the function of the relays.
The selection of each mechanical relay is realised in an array
parameter.
Default values for 5-40 Function Relay:
When 0-03 Regional Settings is set to [0] International, the default
value of Relay1 is 'Alarm', and default value of Relay2 is 'Drive
Running'.
When 0-03 Regional Settings is set to [1] North America, the
default value of Relay1 is 'No Alarm', and default value of Relay2
is 'Drive Running'.
Option:
[82] SL digital
output C
[83] SL digital
output D
[160] No alarm
[161] Running
reverse
[165] Local ref. active The output is high when 3-13 Reference
[166] Remote ref.
active
[167] Start command
activ
[168] Drive in hand
mode
[169] Drive in auto
mode
MG03N102 - Rev. 2013-12-02
Function:
See parameter 13-52 SL Controller Action.
The input goes high whenever the Smart
Logic Action [40] Set dig. out. C high is
executed. The input goes low whenever
the Smart Logic [34] Action Set dig. out. C
low is executed.
See parameter 13-52 SL Controller Action.
The input goes high whenever the Smart
Logic [41] Action Set dig. out. D high is
executed. The input goes low whenever
the Smart Logic [35] Action Set dig. out. D
low is executed.
The output is high when no alarm is
present.
The output is high when the frequency
converter is running counter clockwise
(the logical product of the status bits
'running' AND 'reverse').
Site = [2] Local or when 3-13 Reference
Site = [0] Linked to hand auto at the same
time as the LCP is in [Hand on] mode.
The output is high when 3-13 Reference
Site [1] or Linked to hand/auto [0] while
the LCP is in [Auto on] mode.
The output is high when there is an
active Start command (i.e. via digital
input bus connection or [Hand on] or
[Auto on], and no Stop command is
active.
The output is high when the frequency
converter is in Hand on mode (as
indicated by the LED light above [Hand
on].
The output is high when the frequency
converter is in Hand on mode (as
indicated by the LED light above [Auto
on].
