Danfoss VLT DriveMotor FCP 106 Programming Manual page 86

Parameters
16-72 Counter A
Range:
0 [-32768 -
*
32767 ]
4 4
16-73 Counter B
Range:
0 [-32768 -
*
32767 ]
16-79 Analog Output AO45
Range:
0 mA
*
4.12.7 16-8* Fieldbus & FC Port
Parameters for reporting the BUS references and control
words.
16-86 FC Port REF 1
Range:
0 [-32768 - 32767 ] View the last received reference from the
*
4.12.8 16-9* Diagnosis Read-Outs
16-90 Alarm Word
Range:
0 [0 - 0xFFFFFFFFUL ] View the alarm word sent via the serial
*
16-91 Alarm Word 2
Range:
0 [0 - 0xFFFFFFFFUL ] View the alarm word 2 sent via the
*
16-92 Warning Word
Range:
0 [0 - 0xFFFFFFFFUL ] View the warning word sent via the
*
84
VLT
Function:
View the present value of Counter A. Counters
are useful as comparator operands, see
parameter 13-10 Comparator Operand.
The value can be reset or changed either via
digital inputs (parameter group 5-1* Digital
Inputs) or by using an SLC action
(parameter 13-52 SL Controller Action).
Function:
View the present value of Counter B. Counters
are useful as comparator operands
(13-10 Comparator Operand).
The value can be reset or changed either via
digital inputs (parameter group 5-1* Digital
Inputs) or by using an SLC action
(parameter 13-52 SL Controller Action).
Function:
[0 - 20 mA]
Function:
FC port.
Function:
communication port in hex code.
Function:
serial communication port in hex code.
Function:
serial communication port in hex code.
®
DriveMotor FCP 106 and FCM 106 Programming Guide
16-93 Warning Word 2
Range:
0 [0 - 0xFFFFFFFFUL ] View the warning word 2 sent via the
*
16-94 Ext. Status Word
Range:
0 [0 - 0xFFFFFFFFUL ] Returns the extended status word sent
*
16-95 Ext. Status Word 2
Range:
0 [0 - 0xFFFFFFFFUL ] Returns the extended status word 2
*
MG03N102 - Rev. 2013-12-02
Function:
serial communication port in hex code.
Function:
via the serial communication port in
hex code.
Function:
sent via the serial communication port
in hex code.
