Danfoss VLT DriveMotor FCP 106 Programming Manual page 58

Parameters
5-40 Function Relay
Array (Relay 1 [0], Relay 2 [1])
Select options to define the function of the relays.
The selection of each mechanical relay is realised in an array
parameter.
Default values for 5-40 Function Relay:
When 0-03 Regional Settings is set to [0] International, the default
value of Relay1 is 'Alarm', and default value of Relay2 is 'Drive
4 4
Running'.
When 0-03 Regional Settings is set to [1] North America, the
default value of Relay1 is 'No Alarm', and default value of Relay2
is 'Drive Running'.
Option:
[0] No operation
[1] Control Ready
[2] Drive ready
[3] Drive ready/
remote control
[4] Standby / no
warning
[5] Drive running
[6] Running / no
warning
[7] Run in
range/no
warning
[8] Run on ref/no
warning
[9] Alarm
[10] Alarm or
warning
[12] Out of current
range
[13] Below current,
low
[14] Above current,
high
[16] Below speed,
low
[17] Above speed,
high
[19] Below
feedback, low
[20] Above
feedback, high
56
®
VLT DriveMotor FCP 106 and FCM 106 Programming Guide
Function:
Default for both relays
Control board receives supply voltage.
Frequency converter is ready for
operation and applies supply signal on
control board.
Frequency converter is ready for
operation in Auto On-mode.
Frequency converter is ready for
operation. No start or stop command is
given. No warnings are present.
Motor is running.
Motor runs, and no warning are present.
Motor runs within programmed current
ranges, see parameter 4-50 Warning
Current Low and parameter 4-51 Warning
Current High. No warnings are present.
Motor runs at reference speed and with
no warnings.
An alarm activates output.
An alarm or warning activates output.
Motor current is outside range set in
parameter 4-50 Warning Current Low and
parameter 4-51 Warning Current High.
Motor current is lower than set in
parameter 4-50 Warning Current Low.
Motor current is higher than set in
parameter 4-51 Warning Current High.
MG03N102 - Rev. 2013-12-02
5-40 Function Relay
Array (Relay 1 [0], Relay 2 [1])
Select options to define the function of the relays.
The selection of each mechanical relay is realised in an array
parameter.
Default values for 5-40 Function Relay:
When 0-03 Regional Settings is set to [0] International, the default
value of Relay1 is 'Alarm', and default value of Relay2 is 'Drive
Running'.
When 0-03 Regional Settings is set to [1] North America, the
default value of Relay1 is 'No Alarm', and default value of Relay2
is 'Drive Running'.
Option: Function:
[21] Thermal The thermal warning turns on when the
warning temperature exceeds the limit in motor,
frequency converter or thermistor.
[22] Ready, no Frequency converter is ready for
thermal operation and no over-temperature
warning warning is present.
[23] Remote, ready, Frequency converter is ready for
no thermal operation in Auto mode, and no over-
warning temperature warning is present.
[24] Ready, Voltage Frequency converter is ready for
OK operation and mains voltage is within
specified voltage range.
[25] Reverse Motor runs/is ready to run clockwise
when logic = 0 and counter clockwise
when logic = 1. Output changes as soon
as reversing signal is applied.
[26] Bus OK Active communication (no time-out) via
serial communication port.
[35] External See digital input.
Interlock
[36] Control word Bit 11 in control word controls relay.
bit 11
[37] Control word Bit 12 in control word controls relay.
bit 12
[41] Below
reference, low
[42] Above ref, high
[45] Bus Control
[60] Comparator 0 See parameter group 13-1*. If
Comparator 0 is evaluated as TRUE, the
output will go high. Otherwise, it will be
low.
[61] Comparator 1 See parameter group 13-1*. If
Comparator 2 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[62] Comparator 2 See parameter group 13-1*. If
Comparator 2 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
