Parameters
8-55 Set-up Select
Option: Function:
Select control of the frequency converter set-up
selection via the terminals (digital input) and/or
via the serial communication port.
NOTICE
This parameter is active only when
parameter 8-01 Control Site is set to [0]
Digital and control word.
[0] Digital Activates the set-up selection via a digital input.
input
[1] Bus Activates the set-up selection via the serial
communication port.
[2] Logic Activates the set-up selection via the serial
AND communication port, AND additionally via one of
the digital inputs.
[3] Logic Activate the set-up selection via the serial
*
OR communication port OR via one of the digital
inputs.
8-56 Preset Reference Select
Option: Function:
Select control of the frequency converter Preset
Reference selection via the terminals (digital
input) and/or via the serial communication port.
[0] Digital Activates Preset Reference selection via a digital
input input.
[1] Bus Activates Preset Reference selection via the
serial communication port.
[2] Logic Activates Preset Reference selection via the
AND serial communication port, AND additionally via
one of the digital inputs.
[3] Logic OR Activates the Preset Reference selection via the
*
serial communication port OR via one of the
digital inputs.
4.8.5 8-7* BACnet
8-70 BACnet Device Instance
Range: Function:
1 [0 - 4194303 ] Enter a unique ID number for the BACnet
*
device.
8-72 MS/TP Max Masters
Range: Function:
127 [0 - 127 ] Define the address of the master which holds
*
the highest address in this network. Decreasing
this value optimises polling for the token.
®
VLT DriveMotor FCP 106 and FCM 106 Programming Guide
8-73 MS/TP Max Info Frames
Range:
1 [1 - 65534 ] Define how many info/data frames the device
*
8-74 "I am" Service
Option:
[0] Send at
*
power-up
[1] Continuously
8-75 Intialisation Password
Range:
admin
*
8-79 Protocol Firmware version
Range:
Size related
4.8.6 8-8* FC Port Diagnostics
These parameters are used for monitoring the Bus
communication via the FC Port.
8-80 Bus Message Count
Range:
0 [0 - 65536 ] This parameter shows the number of valid
*
8-81 Bus Error Count
Range:
0 [0 - 65536 ] This parameter shows the number of telegrams
*
8-82 Slave Messages Rcvd
Range:
0 [0 - 65536 ] This parameter shows the number of valid
*
8-83 Slave Error Count
Range:
0 [0 - 65536 ] This parameter shows the number of error
*
MG03N102 - Rev. 2013-12-02
Function:
is allowed to send while holding the token.
Function:
Select when the device should send the "I-
Am" service message only at power-up.
Select when the device should send the "I-
Am" service message continuously with an
interval of approx. 1 min.
Function:
[1 - 1 ] Enter the password needed for execution of
Drive Re-initialisation.
Function:
[0 - 65535 ] Read the supported protocol version.
*
Index 5 is for BACNet.
Function:
telegrams detected on the bus.
Function:
with faults (e.g. CRC fault), detected on the
bus.
Function:
telegrams addressed to the follower, sent by
the frequency converter.
Function:
telegrams, which could not be executed by the
frequency converter.
