Danfoss VLT DriveMotor FCP 106 Programming Manual page 43

Parameters
1-23 Motor Frequency
Range: Function:
NOTICE
Size [ 20 -
related 400
*
This parameter cannot be adjusted
Hz]
while the motor is running.
Select the motor frequency value from the
motor nameplate data. For 87 Hz operation
with 230/400 V motors, set the nameplate
data for 230 V/50 Hz. Adapt
parameter 4-14 Motor Speed High Limit [Hz]
and parameter 3-03 Maximum Reference to the
87 Hz application.
1-24 Motor Current
Range: Function:
NOTICE
Size [ 0.01 -
related 26.0 A]
*
This parameter cannot be adjusted
while the motor is running.
Enter the nominal motor current value
from the motor nameplate data. This
data is used for calculating motor
torque, motor thermal protection etc.
1-25 Motor Nominal Speed
Range: Function:
Size related [100 - 60000 Enter the nominal motor speed
*
RPM] value from the motor nameplate
data. This data is used for
calculating automatic motor
compensations.
1-26 Motor Cont. Rated Torque
Range: Function:
NOTICE
Size related [0.1 - 10000
*
Nm]
Changing this parameter
affects settings of other
parameters.
This parameter is available only
when 1-10 Motor Construction is set
to [1] PM, non-salient SPM.
1-29 Automatic Motor Adaption (AMA)
Option: Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
The AMA function optimises dynamic motor
performance by automatically optimising the
advanced motor parameter 1-30 Stator
®
VLT DriveMotor FCP 106 and FCM 106 Programming Guide
1-29 Automatic Motor Adaption (AMA)
Option:
[0] Off
*
[1] Enable
Complete
AMA
[2] Enable
Reduced
AMA
NOTICE
When 1-10 Motor Construction is set to [1] PM, non-salient
SPM, the only option available is [1] Enable Complete
AMA.
Activate the AMA function by pressing [Hand On] after
selecting [1] or [2]. After a normal sequence, the display
reads: "Press [OK] to finish AMA". After pressing [OK], the
frequency converter is ready for operation.
NOTICE
•
•
•
NOTICE
Avoid generating external torque during AMA.
NOTICE
If one of the settings in parameter group 1-2* Motor
Data is changed, the advanced motor parameters,
parameter 1-30 Stator Resistance (Rs) to
parameter 1-39 Motor Poles, will return to default setting.
MG03N102 - Rev. 2013-12-02
Function:
Resistance (Rs) to parameter 1-35 Main
Reactance (Xh) while the motor is stationary.
No function
Performs AMA of the stator resistance R
stator leakage reactance X
reactance X .
h
NOTICE
Terminal 27 Digital Input
(parameter 5-12 Terminal 27 Digital
Input) has coast inverse as default
setting. This means that AMA cannot be
performed if there is no 24 V to
terminal 27.
Performs a reduced AMA of the stator
resistance R in the system only. Select this
s
option if an LC filter is used between the
frequency converter and the motor.
For the best adaptation of the frequency
converter, run AMA on a cold motor
AMA cannot be performed while the motor is
running
AMA can not be performed on a motor with a
bigger power rating than the frequency
converter, e.g. when a 5.5 kW motor is
connected to a 4 kW frequency converter.
, the
S
and the main
