Parameters
2-17 Over-voltage Control
Option:
[0] Disabled No OVC required.
[2] Enabled Activates OVC.
*
4 4
NOTICE
The ramp time is automatically adjusted to avoid
tripping of the frequency converter.
46
VLT
Function:
Select whether to enable OVC, which reduces the
risk of drive trip due to over voltage on the DC
link caused by generative power from load.
®
DriveMotor FCP 106 and FCM 106 Programming Guide
4.3.2 2-2* Mechanical Brake
Parameters for setting the speed and current of the
mechanical brake.
2-20 Release Brake Current
Range:
0 A [0 - 100 A] Set the motor current for release of the
*
2-22 Activate Brake Speed [Hz]
Range:
0 Hz [0 - 400 Hz] Set the motor frequency for activation of
*

4.4 Main Menu - Reference/Ramps - Group

3
4.4.1 3-0* Reference Limits
Parameters for setting the reference unit, limits and ranges.
Also see parameter group 20-0* Feedback for information
on settings in closed loop.
3-02 Minimum Reference
Range:
0 ReferenceFeed-
backUnit
*
3-03 Maximum Reference
Range:
Size
related ReferenceFeed-
*
backUnit]
MG03N102 - Rev. 2013-12-02
Function:
mechanical brake, when a start condition is
present. The upper limit is specified in 16-37
Inv. Max. Current.
Function:
the mechanical brake, when a stop
condition is present.
[ -4999.0 - 4999 The Minimum
ReferenceFeed- Reference is the
backUnit] lowest value
obtainable by
summing all
references.
Function:
[ -4999.0 - 4999 The maximum reference is the
highest value obtainable by
summing all references. The
maximum reference unit matches
the choice of configuration in
parameter 1-00 Configuration
Mode.
Function:
