Parameters
16-12 Motor Voltage
Range:
0 V [0 - 65535 V] View the motor voltage, a calculated value
*
16-13 Frequency
Range:
0 Hz [0 - 6553.5 Hz] View the motor frequency, without
*
4 4
16-14 Motor current
Range:
0 A [0 - 655.35 A] View the motor current measured as a
*
16-15 Frequency [%]
Range:
0 % [0 - 6553.5
*
%]
16–16 Torque [Nm]
Range:
0.0 [ -30000.0-30000.0
Nm Nm ]
*
16-18 Motor Thermal
Range:
0 % [0 -
*
100 %]
4.12.3 16-2*
16-22 Torque [%]
Range:
0 % [ -200 - 200 % ] View the torque in percent of nominal
*
82
VLT
Function:
used for controlling the motor.
Function:
resonance dampening.
Function:
mean value, I .
RMS
Function:
View a 2-byte word reporting the actual
motor frequency (without resonance
dampening) as a percentage (scale
0000-4000 Hex) of parameter 4-19 Max
Output Frequency.
Function:
View the torque value with sign,
applied to the motor shaft. Some
motors supply more than 160%
torque. So the min. value and the
max. value are dependent on the
max. motor current as well as the
motor used.
Function:
View the calculated motor temperature in
percentage of allowed maximum. At 100% a trip
will occur, if selected in parameter 1-90 Motor
Thermal Protection. The basis for the calculation is
the ETR function selected in
parameter 1-90 Motor Thermal Protection.
Function:
torque, with sign, applied to the motor
shaft.
®
DriveMotor FCP 106 and FCM 106 Programming Guide
16-26 Power Filtered [kW]
Motor power consumption. The value shown is calculated on
basis of the real-time motor voltage and motor current. The
value is filtered, and a few seconds may pass from when an
input value changes to when the data read-out values change.
Range:
0 kW
*
16-27 Power Filtered [hp]
Motor power in hp. The value shown is calculated on the basis
of real-time motor voltage and motor current. The value is
filtered, and a few seconds may pass from when an input value
changes to when the data read-out values change.
Range:
0 hp
*
4.12.4 16-3* Drive Status
16-30 DC Link Voltage
Range:
0 V [0 - 65535 V]
*
16-34 Heatsink Temp.
Range:
0 °C [0 - 255 °C] View the heat sink temperature of the
*
16-35 Inverter Thermal
Range:
0 % [0 - 255 %] View the percentage of thermal load on the
*
16-36 Inv. Nom. Current
Range:
0 A [0 - 655.35 A] View the inverter nominal current, which
*
16-37 Inv. Max. Current
Range:
0 A [0 - 655.35 A] View the inverter maximum current. The
*
16-38 SL Controller State
Range:
0 [0 - 20 ] View the actual state of the Smart Logic
*
MG03N102 - Rev. 2013-12-02
Function:
[0 - 1000 kW]
Function:
[0 - 1000 hp]
Function:
View a measured value.
Function:
frequency converter.
Function:
frequency converter. At 100% a trip occurs.
Function:
should match the nameplate data on the
connected motor. The data are used for
motor protection, etc.
Function:
data are used for calculation of frequency
converter protection, etc.
Function:
Controller (SLC).
