6.1.14 18-** Info & Readouts
Par. Parameter description
No. #
18-1* Fire Mode Log
18-10 FireMode Log:Event
18-5* Ref. & Feedb.
18-50 Sensorless Readout [unit]

6.1.15 20-** Drive Closed Loop

Par. Parameter description
No. #
20-0* Feedback
20-00 Feedback 1 Source
20-01 Feedback 1 Conversion
20-1*
20-12 Reference/Feedback Unit
20-6* Sensorless
20-60 Sensorless Unit
20-69 Sensorless Information
20-8* PI Basic Settings
20-81 PI Normal/ Inverse Control
20-83 PI Start Speed [Hz]
20-84 On Reference Bandwidth
20-9* PI Controller
20-91 PI Anti Windup
20-93 PI Proportional Gain
20-94 PI Integral Time
20-97 PI Feed Forward Factor

6.1.16 22-** Appl. Functions

Par. Parameter description
No. #
22-0* Miscellaneous
22-01 Power Filter Time
22-4* Sleep Mode
22-40 Minimum Run Time
22-41 Minimum Sleep Time
22-43 Wake-Up Speed [Hz]
22-44 Wake-Up Ref./FB Diff
22-45 Setpoint Boost
22-46 Maximum Boost Time
22-47 Sleep Speed [Hz]
22-6* Broken Belt Detection
22-60 Broken Belt Function
22-61 Broken Belt Torque
22-62 Broken Belt Delay
®
VLT DriveMotor FCP 106 and FCM 106 Programming Guide
Default value 2-set-up
0 N/A 1 set-up
0.000 1 set-up
Default value 2-set-up
[0] No function All set-ups
[0] Linear All set-ups
ExpressionLimit, All set-ups
ExpressionLimit All set-ups
0 N/A 1 set-up
[0] Normal All set-ups
0.0 Hz All set-ups
5.0% All set-ups
[1] On All set-ups
0.5 All set-ups
20 s All set-ups
0.0% All set-ups
Default value 2-set-up
0.50s All set-ups
10.0 s All set-ups
10.0 s All set-ups
10.0 Hz All set-ups
10.0% All set-ups
0.0% All set-ups
60 s All set-ups
0.0 s All set-ups
[0] Off All set-ups
10% All set-ups
10 s All set-ups
MG03N102 - Rev. 2013-12-02
Change during Conver-
operation sion index
TRUE 0
FALSE -3
Change during Conver-
operation sion index
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -
TRUE -1
TRUE 0
TRUE -
TRUE -2
TRUE -2
TRUE 0
Change during Conver-
operation sion index
TRUE -2
TRUE 0
TRUE 0
TRUE -1
TRUE 0
TRUE 0
TRUE 0
TRUE -1
TRUE -
TRUE 0
TRUE 0
Type
Uint8
Int32
Type
6 6
Uint8
Uint8
Uint8
Uint8
VisStr[25]
Uint8
Uint16
Uint8
Uint8
Uint16
Uint32
Uint16
Type
Uint16
Uint16
Uint16
Uint16
Uint8
Int8
Uint16
Uint16
Uint8
Uint8
Uint16
109
