Parameters
6-10 Terminal 53 Low Voltage
Range:
0.07 V [0 - 10
*
V]
4 4
6-11 Terminal 53 High Voltage
Range:
10 V [0 - 10 V] Enter the voltage (V) that corresponds to the
*
6-12 Terminal 53 Low Current
Range:
4 mA [0 - 20
*
mA]
6-13 Terminal 53 High Current
Range:
20 mA [0 - 20
*
mA]
6-14 Terminal 53 Low Ref./Feedb. Value
Range:
0 [-4999 -
*
4999 ]
6-15 Terminal 53 High Ref./Feedb. Value
Range:
Size
related 4999 ]
*
6-16 Terminal 53 Filter Time Constant
Range:
0.01 s [0.01 - 10
*
s]
60
Function:
Enter the voltage (V) that corresponds to
parameter 6-14 Terminal 53 Low Ref./Feedb.
Value. The value must be set at >1 V to
activate parameter 6-01 Live Zero Timeout
Function.
Function:
high reference value (set in 6-15 Terminal 53
High Ref./Feedb. Value).
Function:
Enter the low current value. This reference
signal should correspond to the low reference/
feedback value, set in parameter 6-14 Terminal
53 Low Ref./Feedb. Value. The value must be set
at >2 mA to activate the Live Zero Time-out
Function in parameter 6-01 Live Zero Timeout
Function.
Function:
Enter the high current value corresponding
to the high reference/feedback set in
parameter 6-15 Terminal 53 High Ref./Feedb.
Value.
Function:
Enter the reference or feedback value that
corresponds to the voltage or current set in
parameter 6-10 Terminal 53 Low Voltage to
parameter 6-12 Terminal 53 Low Current.
Function:
[-4999 - Enter the reference or feedback value
that corresponds to the voltage or
current set in parameter 6-11 Terminal
53 High Voltage to
parameter 6-13 Terminal 53 High
Current.
Function:
Enter the time constant. This is a first-order
digital low pass filter time constant for
suppressing electrical noise in terminal 53.
A high time constant value improves
®
VLT DriveMotor FCP 106 and FCM 106 Programming Guide
6-16 Terminal 53 Filter Time Constant
Range:
6-19 Terminal 53 mode
Option:
[0] Current mode
[1] Voltage mode
*
4.7.3 6-2* Analog Input 54
Parameters for configuring the scaling and limits for
analog input 54 (terminal 54).
6-20 Terminal 54 Low Voltage
Range:
0.07 V
*
6-21 Terminal 54 High Voltage
Range:
10 V
*
6-22 Terminal 54 Low Current
Range:
4 mA
*
6-23 Terminal 54 High Current
Range:
20 mA
*
20.00
mA
*
MG03N102 - Rev. 2013-12-02
Function:
dampening but also increases the time
delay through the filter.
Function:
Select if terminal 53 is used for current- or
voltage input.
Function:
[0 - 10 Enter the voltage (V) that corresponds to the
V] low reference value (set in
parameter 6-24 Terminal 54 Low Ref./Feedb.
Value). The value must be set at >1 V to
activate parameter 6-01 Live Zero Timeout
Function.
Function:
[0 - 10 V] Enter the voltage (V) that corresponds to the
high reference value (set in
parameter 6-25 Terminal 54 High Ref./Feedb.
Value).
Function:
[0 - 20 Enter the low current value. This reference
mA] signal should correspond to the low reference/
feedback value, set in parameter 6-24 Terminal
54 Low Ref./Feedb. Value. The value must be set
at >2 mA to activate the Live Zero Timeout
Function in parameter 6-01 Live Zero Timeout
Function.
Function:
[0 - 20 mA] Enter the high current value
[par. 6-22-20.00 corresponding to the high
mA] reference/feedback value set in
parameter 6-25 Terminal 54 High Ref./
Feedb. Value.
