Parameters
8-33 Parity / Stop Bits
Option: Function:
[2] No Parity, 1 Stop Bit
[3] No Parity, 2 Stop Bits
8-35 Minimum Response Delay
Range: Function:
0.01 s [ 0.0010 - 0.5 Specify the minimum delay time
*
s] between receiving a request and
transmitting a response. This is used for
overcoming modem turnaround delays.
8-36 Maximum Response Delay
Range: Function:
Size [ 0.1 - Specify the maximum permissible
related 10.0 s] delay time between receiving a
*
request and transmitting the response.
If this time is exceeded, no response is
returned.
4.8.3 8-4* MC Protocol Set
8-42 PCD Write Configuration
Different parameters can be assigned to PCD 3 to 10 of the
PPOs. The number of PCDs depends on the PPO type.
The values in PCD 3 to 10 are written to the selected parameters
as data values.
Option:
[0] None
[1] [302] Minimum Reference
[2] [303] Maximum Reference
[3] [341] Ramp 1 Ramp up time
[4] [342] Ramp 1 Ramp down time
[5] [351] Ramp 2 Ramp up time
[6] [352] Ramp 2 Ramp down time
[7] [380] Jog Ramp Time
[8] [381] Quick Stop Time
[9] [412] Motor Speed Low Limit
[Hz]
[10] [414] Motor Speed High Limit
[Hz]
[11] [590] Digital & Relay Bus
Control
[12] [676] Terminal45 Output Bus
Control
[13] [696] Terminal 42 Output Bus
Control
[14] [894] Bus Feedback 1
[15] FC Port CTW
[16] FC Port REF
®
VLT DriveMotor FCP 106 and FCM 106 Programming Guide
8-43 PCD Read Configuration
Different parameters can be assigned to PCD 3 to 10 of the
PPOs. The number of PCDs depends on the PPO type.
PCD 3 to 10 will hold the real-time data value of the selected
parameters.
Option:
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
Function:
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
[32]
[33]
[34]
4.8.4 8-5* Digital/Bus
Parameters for configuring the control word Digital/Bus
merging.
8-50 Coasting Select
Option:
MG03N102 - Rev. 2013-12-02
None
[1500] Operation Hours
[1501] Running Hours
[1502] kWh Counter
[1600] Control Word
[1601] Reference [Unit]
[1602] Reference %
[1603] Status Word
[1605] Main Actual Value [%]
[1609] Custom Readout
[1610] Power [kW]
[1611] Power [hp]
[1612] Motor Voltage
[1613] Frequency
[1614] Motor Current
[1615] Frequency [%]
[1618] Motor Thermal
[1630] DC Link Voltage
[1634] Heatsink Temp.
[1635] Inverter Thermal
[1638] SL Controller State
[1650] External Reference
[1652] Feedback [Unit]
[1660] Digital Input 18,19,27,33
[1661] Terminal 53 Switch
Setting
[1662] Analog Input 53(V)
[1663] Terminal 54 Switch
Setting
[1664] Analog Input 54
[1665] Analog Output 42 [mA]
[1671] Relay Output [bin]
[1672] Counter A
[1673] Counter B
[1690] Alarm Word
[1692] Warning Word
[1694] Ext. Status Word
Function:
Select control of the coasting function via the
terminals (digital input) and/or via the bus.
Function:
